GENERAL SPECIFICATIONS

OPTICAL:
Number of rows
Number of digits/row
Dot matrix
Digit height)
Digit width
Character config.
Brightness (typical)
Display color
MTBF (hours)
MECHANICAL:
Weight
Dimensions (in inches)
Display head
Rectangular base
Base plate
Overall height (typical)
ELECTRICAL:
Adapter input power
Adapter output power
ENVIRONMENTAL:
Operating temperature
Storage temperature
Relative Humidity
Vibration (10 to 55 Hz.)
Shock
CABLES & CONNECTORS:
Serial
Display cable
Interface cable
Power adapter
Parallel
Display cable
LD9000
2
20
5 x 7
0.374in. (9.5mm)
0.244in. (6.2mm)
ASCII
2
900 cd/m
Blue-Green
300,000
2.7 lb.
(w x h x d)
8.50 x 3.37 x 1.75
2.12 x 2.0 x 2.25
4.0 x 0.09 x 8.0
24
120VAC, 60Hz; optional 220VAC, 50Hz
7.5VAC, 1000mA
o
0 to +50 C
o
-20 to +70 C
80%, non-condensing
4G's
40G's
8-pin Mini DIN (male)
8-pin Mini Din (female)
DB9 (female); optional DB25 (female)
Phone jack (male)
Phone jack (female)
DB25 (female)
13
LD9000X
2 x 2 sides
20
5 x 7
0.374in. (9.5mm)
0.244in. (6.2mm)
ASCII
2
900 cd/m
Blue-Green
300,000
2.7 lb.
(w x h x d)
8.50 x 3.37 x 1.75
2.12 x 2.0 x 2.25
4.0 x 0.09 x 8.0
24
