Protimeter TimberMaster BLD5605 Instruction Manual page 5

damaged.
7
Reference Mode
Measure the material until the meter's reading is stable
then press for 2 seconds. This will store the reading
until the mode changes or the meter turns off. Now all
readings taken after will be displayed as normal, but
below you will see a second reading that shows you if the
material is measured above or below the original reading.
Reference mode can be useful when trying to establish
what materials are above or below a point of reference or
dry standard. See page 6 for further information.
8
Operating TimberMaster
8.1 Switch On:
Press the ON/OFF button.
The unit turns on, with the LCD displaying all the
segments and sweeping the LED bar graph.
Protimeter TimberMaster Page 5
