Autel MaxiTPMS TBE100 Quick Reference Manual

Email: sales@autel.com

Web: www.autel.com

Thank you for purchasing this AUTEL tire tread & brake disc laser examiner. Our tool is manufactured to a high standard

and will give you years of trouble-free performance when used according to these instructions and properly

maintained.

IMPORTANT: This tool is a class 3R laser product. Avoid direct eye exposure to the laser. Failure to observe

the warning may result in serious injury.

NOTE:

To use the Generate Report and Report Query functions, you need to update the TBE device software to

V01.19.00 or later. For update details, see the Quick Reference Guide for the TBE device.

When updating software, ensure the TBE device is connected to the Internet and that its battery is charged

to at least 50 percent or it is connected to a power outlet.

Generating Report

IMPORTANT: Before operating or maintaining this tool, please read the Quick Reference Guide and User

Manual for the TBE device carefully, paying extra attention to the safety warnings and precautions. Use this

tool correctly and properly. Failure to do so may cause damage and/or personal injury and will void the

product warranty.

Quick Reference Guide

MaxiTPMS

Refer to the Quick Reference Guide for the TBE

device to perform a tire tread check or brake disc

check.

Tap Data Query from the Main Menu and tap Last

Test to view the latest test result.

Scroll up and tap Generate Report. The Generating

Report screen appears.

(For Generating Report)

TBE100/TBE200

Table of Contents

Do you have a question about the MaxiTPMS TBE100 and is the answer not in the manual?

Page 1 TBE100/TBE200 ® Thank you for purchasing this AUTEL tire tread & brake disc laser examiner. Our tool is manufactured to a high standard and will give you years of trouble-free performance when used according to these instructions and properly maintained.
Page 2 Select or enter the vehicle information to associate the vehicle with the test data and tap Next to generate a report. Note: Information marked with red asterisk (*) is required. After the report is successfully generated, tap Check. Use your mobile device to scan the QR code and download the report. Querying Report Tap Data Query from the Main Menu and tap Report Query to view report records.
