AENO DB7 Manual

EN Toothbrush AENO DB7/DB8 is designed for daily cleaning of teeth and gums.
Specifications
Battery: Non-removable 3.7 V lithium-ion (DC), 800 mAh. Full charge time: 4 h. Power:
0.5 W. Noise level (at 0.3 m): ≤60 dB. Body protection degree: IPX7. Stiffness of the bristles:
soft. Number of
Ø 21 mm × 208 mm.
Scope of Delivery (figure a, d, e)
Toothbrush AENO DB7/DB8 (white) (handle (1), removable head (2) (DB7 – 1 pc., DB8 –
3 pcs.)), power cord micro-USB / USB Type-A (0.3 m), quick start guide, warranty card, (DB7 –
2 stickers, DB8 – metal tool (1 pc.), mirror (1 pc.)).
Limitations and Warnings
This appliance is not intended for use by children or persons with reduced physical, sensory
or mental capabilities if they have inadequate experience or knowledge of how to use the
appliance, or if they are not under the supervision of a person responsible for their safety. If
you have diseases of the teeth, gums and mouth, you should first consult a dentist about
the possibility of using the device. Replace the brush head at least every three months,
depending on wear. Do not perform maintenance on the device and its components until
the device is turned off and disconnected from the power supply. Do not wash the unit or
any part of it in the dishwasher. When washing, do not immerse the brush handle and the
head completely in water (figure c), do not use aggressive cleaning agents. It is acceptable
to occasionally treat the bristles of the head with mouthwash. Dirt on the handle of the
device should be removed with a damp cloth. Do not disassemble or attempt to repair the
unit yourself.
Preparing the device for operation
Remove the cover (3). Connect the device to the mains using the USB cable and the
AC adapter. When the LED indicator (4) lights green, the battery is fully charged, and the
device is ready for use. Charge the device for at least 24 hours before using it for the first
time. If you brush your teeth twice a day for 2 minutes, the device will work without a charge
for up to 3 months.
ATTENTION! The AC adapter is not included in the package. You can use any adapter with
a 5.0 V / 0.3 A (DC) power setting.
Operating the device
Install the replacement head (2) on the handle (1) as shown in figure b. Press the power
button (8). The indicator (4) will light up, as well as one of the indicators that show the
operating mode of the device. To turn the device off, press the button (8) again.
Every 30 seconds, the vibration alarm goes off, reminding you to switch the operating
mode. To change the mode, switch the device off and on again with button (8). Then quickly
press the button (8) several times in a row to select the desired mode. Each time you press
it, the mode changes to the next.
Operating modes of the device (figure a)
• "Soft" (5) – delicate cleaning of sensitive areas
• "Clean" (6) – daily standard cleaning
• "White" (7) – teeth whitening
Troubleshooting
• The replaceable head vibrates poorly. Possible reason: the head fits too tightly on the
handle of the device. Solution: make sure that there is a small gap at the mating point (9),
about 0.5 mm.
• Short operating time after a full charge. Possible reason: the device has not been used
for more than 6 months, so the battery does not hold a charge very well. Solution: contact
the service center and replace the device battery.
These symbols mean that you must follow the Waste Electrical and Electronic Equipment (WEEE)
and Waste Battery and Battery Regulations when disposing of the device, its batteries and
accumulators, and its electrical and electronic accessories. According to the rules, this equipment
must be disposed of separately at the end of its service life.
Do not dispose of the device, its batteries and accumulators, or its electrical and electronic
accessories together with unsorted municipal waste, as this will harm the environment. To dispose
of this equipment, it must be returned to the point of sale or taken to a local recycling facility. You
should contact your local household waste disposal service for details.
The warranty period and service life is 2 years from the date of purchase of the product.
Manufacturer information: ASBISc Enterprises PLC, Agios Athanasios, Lapetou 1, 4101 Limassol,
Cyprus. Made in China. Up-to-date information and a detailed description of the device, as well as
connection instructions, certificates, information on companies that accept quality claims and
warranties, are available for download at aeno.com/documents. All trademarks and brand names are the property of
their respective owners.
ASBISc reserves the right to modify the device and to make edits and changes to this document without prior notice
to users and shall not be liable for possible negative consequences resulting from the use of an outdated version of
the document or for any possible technical or typographical errors or omissions or incidental or consequential
damages that may arise from the transmission of this document or the use of devices.
aeno.com/documents
operation modes: 3. Dimensions of the brush with head:
