oWNERS
MANuAL
Model No.
45-02181
CAUTION:
Read Rules for
Safe Operation
and Instructions
Carefully
PRINTED IN USA
™
26" LEAF/LAWNSWEEPER
Safety
Assembly
operating
Maintenance

Repair Parts

the fastest way to purchase parts www.speedepart.com
FORM NO. 40261 (4/24/07)

Advertisement

Table of Contents
loading

Related Manuals for Agri-Fab 26" Leaf/Lawnsweeper 45-02181

Summary of Contents for Agri-Fab 26" Leaf/Lawnsweeper 45-02181

  • Page 1: Repair Parts

    ™ oWNERS MANuAL Model No. 45-02181 CAUTION: Read Rules for Safe Operation and Instructions Carefully PRINTED IN USA 26" LEAF/LAWNSWEEPER Safety Assembly operating Maintenance Repair Parts the fastest way to purchase parts www.speedepart.com FORM NO. 40261 (4/24/07)

  • Page 2: Safety Rules

    Remember, any equipment can cause injury if operated improperly or if the user does not understand how to operate the equipment. Exercise caution at all times when using this equipment. LooK FoR THIS SYMBoL To PoINT ouT IMPoRTANT SAFETY PRECAuTIoNS. IT MEANS —...

  • Page 3: Tools Required For Assembly

    HARDWARE PACK (NoT SHoWN FuLL SIZE) Ref. Description Hex Bolt, 1/4-20 x 1-1/4" Flat Washers 1/4" I.D. Hex Lock Nuts 1/4-20 Bag Rod Clips Curved Head Bolts 1/4-20 x 1" Palnut 1/4" Plastic Caps (for bag rods) Plastic Caps (for leg stands) ASSEMBLY INSTRuCTIoNS TooLS REQuIRED FoR ASSEMBLY (1) Phillips Screwdriver...
  • Page 4 3. Now tighten the four bolts from step 1. 4. Assemble a bag rod clip to the inside of each lower handle tube using a curved head bolt secured down against the clip using a 1/4" lock nut. The open end of the clips should face towards the sweeper housing.

  • Page 5: Operation

    9. Place the upper hopper bag and bag rod into the bag rod clips on the hopper handle. See figure 7. FIGuRE 7 10. Place the lower hopper bag and bag rod into the opening on the sweeper housing. See figure 8. FIGuRE 8 11. Hook the elastic straps on the bag flaps under the bag rod clips on the lower handle tubes as shown in figure FIGuRE 9 oPERATIoN Take care when operating your sweeper. Operating your sweeper according to these instructions will help prevent damage and prolong the life of your sweeper.

  • Page 6: Lubrication/Maintenance

    CAuTIoN: EYE PRoTECTIoN SHouLD BE WoRN WHILE oPERATING SWEEPER DuMPING oF SWEEPER To dump sweeper hopper bag, simply tip the sweeper forward or lift off the complete hopper bag frame. Always dump hopper after each use. Damp or wet grass and leaves will cause damage to hopper if stored for long periods of time.

  • Page 7: Brush Replacement

    BRuSH REPLACEMENT 1. Remove the hopper bag from lawnsweeper. 2. Brush replacement should be done one brush at a time. 3. Tip the sweeper forward on housing for ease of brush replacement. Do not remove hex bolt from double brush retainers through brush shaft. 4.
  • Page 8 REPAIR PARTS FoR 45-02181 26" LEAF/LAWNSWEEPER...
  • Page 9 REPAIR PARTS FoR 45-02181 26" LEAF/LAWNSWEEPER REF. PART QTY. DESCRIPTIoN 44600 Housing 23784 Height Adjustment Plate 44286 Bolt, Hex 10-32 x 5/8" 43681 Bolt, Carriage 5/16-18 x 1-1/2" 44680 Washer, Nylon 1543-69 Washer, Nylon 21/64 44695 Washer, Bowed R19111116 Washer, 11/32 x 11/16 43720 Knob, 5/16"...
  • Page 10 NoTES...
  • Page 11 NoTES...
  • Page 12 Agri-Fab, Inc. Unauthorized uses and/or reproductions of this manual will subject such unauthorized user to civil and criminal penalties as provided by the United States Copyright Laws.
