The VIGILANT T-Gen2 is a self-contained Grade 3 Emergency Warning System (EWS) with 100V speaker line
supervision and digitised speech messages. It has been designed to comply with AS 4428.16.
It is available as a self-contained Building Occupant Warning System (BOWS) complete with PSU, User Interface and
microphone in two cabinet sizes, 8U and 18U (see later for a full list of available items and accessories):
FP1136
8U 60W BOWS: A complete Building Occupant Warning System (BOWS) including a T-Gen 60, 5A
PSU, 3U 19" rack mounting door with Grade 3 User Interface and microphone mounted in a titania-
coloured 8U cabinet. Space for an additional T-Gen 60 and up to two 17Ahr batteries, 3 x 100V
Switching or 100V Splitter modules is available. Note the 5A PSU may limit the expansion T-Gen 2
load capacity.
18U 120W BOWS: A complete BOWS including a T-Gen 120, 10A PSU, 3U 19" rack mounting door
FP1137
with Grade 3 User Interface and microphone, mounted in a cream coloured 18U x 310 deep rack
cabinet. Space for up to 75Ahr batteries (but not including 65Ahr batteries), additional T-Gen 120, and
up to 8 x 100V Switching or 100V Splitter modules is available. Note the 10A PSU may limit the
expansion T-Gen 120 load capacity.
Optional modules that can be fitted into the T-Gen2 BOWS include:
FP1115
T-Gen 60: A second 60W T-Gen2 can be fitted to the FP1136 BOWS to expand the power output.
FP1116
T-Gen 120: A second 120W T-Gen2 can be fitted to the FP1137 BOWS to expand the power output.
100V Switching Module: This splits the T-Gen2's 100V output into 4 short-circuit isolated outputs
FP1117
that can also be used to direct paging announcements to specific areas.
100V Splitter Module: This splits the T-Gen2's 100V output into 4 short-circuit isolated outputs. No
FP1118
control of the outputs is possible.
SU0360
A 4488 4 Zone Paging Console: A 4 zone paging console with microphone and chime option that
can be used with the SU0361 A 4489 Audio Switcher to achieve 4 area paging from remote locations.
Up to two paging consoles can be connected to the SU0361 Audio Switch.
SU0361
A 4489 Audio Switcher: Used with the A 4428 4 zone paging console to provide relay outputs. Able
to be mounted inside the BOWS cabinet.
These instructions (LT0676) cover the installation and configuration of the BOWS. For installation and operation of the
included and optional modules refer to the following documents:
LT0667 LIT,T-GEN2 60/120 INSTALLATION & OPERATION MANUAL
LT0668 LIT,T-GEN 100V SWITCHING MODULE INSTALL INSTRUCTIONS
LT0671 LIT,T-GEN 100V SPLITTER MODULE INSTALL INSTRUCTIONS
LT0672 LIT,GRADE 3 USER INTERFACE INSTALLATION GUIDE
LT0673 LIT,GRADE 3 USER INTERFACE OPERATING INSTRUCTIONS
CHECKING THE BOWS
Before commencing installation, please ensure that the following items are present and undamaged:
FP1136, 8U 60W BOWS
1 x T-Gen 60W Board
1 x 5A PSU
1 x T-Gen2 Installation Instructions (LT0667).
1 x Grade 3 User Interface Operating Instructions (LT0673)
1 x BOWS Installation Instructions (LT0676 – this document).
1 x LM0359, battery lead
6 x HW0302, clip-in cable tie mount
1 x LT0675, factory completed BOWS checklist
1 x LT0435, cabinet wall mounting template
1 x KT0575 kit of parts, including:
1 x 3k3, 6 x 10k, 1 x 15k, 3 x 27k, 1 x 56k, 2 x 100k, 1 x LB0648 Warning Label, 220mm length of 3mm heat
shrink, 4 x M4 x 10 screws
1 x KT0576 kit of parts, including 4 x M5 x 12 screws, nuts, washers
LT0676 Issue 1.00
T-Gen2 Building Occupation
Warning System
INSTALLATION INSTRUCTIONS
6 December 2017
Page 1 of 8
Advertisement
Table of Contents
Related Manuals for Vigilant T-Gen2
Summary of Contents for Vigilant T-Gen2
- Page 1 Optional modules that can be fitted into the T-Gen2 BOWS include: FP1115 T-Gen 60: A second 60W T-Gen2 can be fitted to the FP1136 BOWS to expand the power output. FP1116 T-Gen 120: A second 120W T-Gen2 can be fitted to the FP1137 BOWS to expand the power output.
- Page 2 T-Gen2 is programmed with the BOWS configuration. This sets up the T-Gen2 with the Grade 3 User Interface, the ALARM input to trigger AS 4428.16 evacuate tones and message, the AIE input as an EXT PSU Fault (wired from the PSU), AUDIO IN 1 as always enabled background music, and GP1 as an input to activate AUDIO IN 2 on demand (e.g., to enable an external all-area paging microphone).
- Page 3 Figure 1 - BOWS Cabinet Mounting Details This is a Class A product. In a domestic environment this product may cause radio interference, in which case the user may be required to take adequate measures. External Wiring 8U Cabinet Cable Entry There are four Ø20mm and two Ø50mm and knockouts provided in the top and bottom of the cabinet, as well as a Ø20mm knockout provided in the top for mains wiring entry.
- Page 4 Factory Wiring The PSU 24V output is wired to the T-Gen2 +24V terminals and the PSU Charger Flt- signal is wired to the A/I/E- input. The default BOWS configuration for T-Gen2 sets the A/I/E- input as External PSU Fault, allowing a PSU fault to signal via the T-Gen2.
- Page 5 The BOWS is supplied with a 5A (FP1136) or 10A (FP1137) maximum current PSU. This limits the load that can be connected to the T-Gen2 units, as AS 1670.1:2015 requires the PSU to be able to supply the full alarm load without any batteries connected.
- Page 6 24 AHr This provides 24 hour standby operation with the T-Gen2 in the audio-enabled state, plus 30 minutes in alarm at the full load supported by that BOWS unit. There is reserve capacity to power one 100V Switching or 100V Splitter Module as well.
- Page 7 QBus compliant Master / Slave operation, User Interface and Master / Slave operation, User Interface and 100V Switching Module 100V Switching Module Slave T-Gen2 RJ45 cable within cabinet RJ45 cable within cabinet On-board Storage 4MB (configuration and audio files) 4MB (configuration and audio files)
- Page 8 T-Gen60 or T-Gen120 mounted inside the cabinet. A 1.5m power loom and microphone extension loom are included, long enough to connect to the T-Gen2 mounted on the gear plate in a 40U deep cabinet, for example. Can be used as a spare part for the User Interface.
