  • Page 2 About This Manual Thank you for choosing the Akuvox A02 access control terminal. This manual is intended for the administrators who need to properly configure the access control terminal. This manual is written based on firmware version: 101.30.4.10, and it provides all the configurations for the functions and features of A01, A02, and A03 access control terminals.
  • Page 3 Introduction of Icons and Symbols Note Informative information and advice from the efficient use of the device. • • Useful information for the quick and efficient use of the device.
  • Page 4 Related Documentation You are advised to refer to the related documents for more technical information via the link below: https://knowledge.akuvox.com...

  • Page 5: Table Of Contents

    Content 1 Product Overview ..................7 2 Change Log....................8 3 Model Specification ..................9 4 Introduction to Configuration Menu ............11 5 Access the Device ..................12 6 Time Setting ....................14 7 LED Setting....................16 7.1 Brightness Setting ..................16 8 Volume and Tone Configuration ..............
  • Page 6 17 Backup....................40 18 Auto-provisioning ..................41 18.1 Provisioning Principle ................41 18.2 Configuration Files for Auto-provisioning..........42 18.3 AutoP Schedule..................42 18.4 DHCP Provisioning Configuration............43 18.5 Static Provisioning Configuration ............45 19 Integration with Third Party Device ............47 19.1 Integration via Wiegand ................. 47 19.2 Integration via HTTP API ................48 19.3 Power Output..................

  • Page 7: Product Overview

    Akuvox A02 Access Control Terminal Admin Guide 1 Product Overview Akuvox Access control terminals A02 incorporate a door controller and an RIFD reader in one standalone device, thus saving your solution costs. It is equipped with a card reader (125kHz and 13.5MHz) which is currently capable of handling a majority of cards in wide use.

  • Page 8: Change Log

    Akuvox A02 Access Control Terminal Admin Guide 2 Change Log The change log will be updated here along with the changes in the new software version. www.akuvox.com...

  • Page 9: Model Specification

    Akuvox A02 Access Control Terminal Admin Guide 3 Model Specification Model & Feature Front panel: Toughened Glass Housing Material Frame: Aluminum Alloy Relay Out Input Wiegand √ √ 64MB 64MB Card Reader 13.56MHz&125KHz Wi-Fi Bluetooth IP Rating IP65 www.akuvox.com...
  • Page 10 Akuvox A02 Access Control Terminal Admin Guide External SD Card Wall Mounting √ Flush Mounting √ Desk Mounting www.akuvox.com...

  • Page 11: Introduction To Configuration Menu

    PCAP, password modification as well as device backup. Tool selection: Akuvox has many configuration tools for you to set up devices more conveniently. Here we list some common tools, please contact your administrator to get the tool if you need them.

  • Page 12: Access The Device

    Before configuring Akuvox A02, please make sure the device is installed correctly and connects to a normal network. Using the Akuvox IP scanner tool to search the device IP address in the same LAN. Then use the IP address to log in to the web browser by user name and password admin and admin.
  • Page 13 Akuvox A02 Access Control Terminal Admin Guide • You can also obtain the device IP address using the Akuvox IP scanner to log in to the device web interface. Please refer to the URL below for the IP scanner application: https://knowledge.akuvox.com/docs/how-to-obtain-ip-...

  • Page 14: Time Setting

    Akuvox A02 Access Control Terminal Admin Guide 6 Time Setting Time setting on the web interface allows you to set up time and date manually while allowing you to use the NTP server address that you obtained to automatically synchronize your time and date.
  • Page 15 Akuvox A02 Access Control Terminal Admin Guide • Automatic Date&Time Enabled: if enabled, the device will update the time automatically via the NTP server (Network Time Protocol). Disable it if you want to set up the time manually. • Time Zone: select the specific time zone based on where the device is used. The default time zone is GMT+0:00.

  • Page 16: Led Setting

    Akuvox A02 Access Control Terminal Admin Guide 7 LED Setting 7.1 Brightness Setting If you want to brighten up the brightness in order to see the card reader at greater ease in an environment with higher light intensity, you need to set up the related parameters in the web Device >Light >...

  • Page 17: Volume And Tone Configuration

    Akuvox A02 Access Control Terminal Admin Guide 8 Volume and Tone Configuration Volume and tone configuration in A02 access control terminal refers to tamper alarm volume, voice prompt volume, and open-door tone configuration. Moreover, you can upload the tone you like to enrich your personalized user experience.

  • Page 18: Upload Open Door Tone

    Akuvox A02 Access Control Terminal Admin Guide 8.2 Upload Open Door Tone You can upload the tone for open door failure and success on the device web interface. To upload the tones, go to Device > Audio > Open Door Tone Setting interface.

  • Page 19: Network Setting

    Akuvox A02 Access Control Terminal Admin Guide 9 Network Setting You can configure the default DHCP mode (Dynamic Host Configuration Protocol) and static IP connection. Moreover, you can set up an IP address, Subnet Mask, Default Gateway, and DNS servers. To configure the configuration on web Network > Basic > LAN Port interface.

  • Page 20: Relay Setting

    Akuvox A02 Access Control Terminal Admin Guide 10 Relay Setting You can configure the relay switch(es) for door access on the web interface. 10.1 Relay Switch Setting To configure the configuration on web Access Control > Relay > Relay interface.

  • Page 21: Web Relay Setting

    Akuvox A02 Access Control Terminal Admin Guide 10.2 Web Relay Setting In addition to the relay that is connected to the access control terminal, you can also control the door access using the network-based web relay on the device and the device web interface.
  • Page 22 Akuvox A02 Access Control Terminal Admin Guide • Local Relay + Web relay: if it is selected, both the local relay and web relay will be triggered for the door opening. In the DTMF code door opening, if the web relay and local relay share the same DTMF code, the local relay will be triggered first.

  • Page 23: Door Access Schedule Management

    Akuvox A02 Access Control Terminal Admin Guide 11 Door Access Schedule Management You are required to configure and make a schedule for the user-based door access via RF card, and private PIN. 11.1 Configure Door Access Schedule You can create door access schedules so that they can be later conveniently applied to the door access control intended for individual users or a group of users created.

  • Page 24: Create Door Access Schedule

    Akuvox A02 Access Control Terminal Admin Guide 11.1.2 Create Door Access Schedule You can create the door access schedule on a daily or weekly basis, and you can also create a schedule that allows you to plan for a longer time in addition to running the door access schedule on a daily or monthly basis.
  • Page 25 Akuvox A02 Access Control Terminal Admin Guide To create a daily schedule, select Weekly mode: Parameter Set-up: • Day of Week: select the day(s) on which door access can be valid on a weekly. To create a longer period schedule: Parameter Set-up: •...

  • Page 26: Import And Export Door Access Schedule

    Akuvox A02 Access Control Terminal Admin Guide 11.1.3 Import and Export Door Access Schedule In addition to creating door access schedules separately, you can also conveniently import or export the schedules to maximize your door access schedule management efficiency. To configure the configuration on web Setting > Schedule interface.

  • Page 27: Door Unlock Configuration

    Akuvox A02 Access Control Terminal Admin Guide 12 Door Unlock Configuration A02 access control terminal offers you three types of door access via RF card. You can configure them on the web interface. Moreover, you can import or export the configured files including access control information.

  • Page 28: Configure Rf Card Code Format

    NFC (Near Field Communication) is a popular way for door access. It uses radio waves for data transmission interaction. A02 can be unlocked by NFC. You can keep the mobile phone closer to the door phone for door access. To configure the configuration on web Access Control >...

  • Page 29: Unlock By Http Command On Web Browser

    Akuvox A02 Access Control Terminal Admin Guide Note • NFC feature is only supported by Android telephones. Unlock by HTTP Command on Web Browser 12.3 You can unlock the door remotely without approaching the device physically for door access by typing in the created HTTP command (URL) on the web browser to trigger the relay when you are not available by the door for door opening.

  • Page 30: Unlock By Exit Button

    • Door Status: display the status of the input signal. 12.5 Unlock by PIN Code A02 supports opening the door via pin code. You can set up a PIN code on the Directory > User, click Add, then type in the private PIN code.

  • Page 31: Unlock By Public Code

    After the configuration, the PIN will be displayed on the user interface. 12.6 Unlock by Public Code A02 supports public pin codes for administrators or cleaners to open the door. You can set up a public PIN code on Access Control > Relay > Public PIN interface.

  • Page 32: Access Authentication Mode

    Akuvox A02 Access Control Terminal Admin Guide 12.7 Access Authentication Mode 12.7.1 Access Authentication Mode Configuration A02 supports dual access authentication mode. You can set up the dual access authentication mode on Access Control > Relay> Access Authentication Mode interface. Parameter Set-up: •...

  • Page 33: Security

    Akuvox A02 Access Control Terminal Admin Guide 13 Security 13.1 Tamper Alarm Setting The tamper alarm function serves as a protection against any unauthorized removal of the devices by triggering off the temper alarm on the device. To configure the configuration on web System >...
  • Page 34 Akuvox A02 Access Control Terminal Admin Guide Parameter Set-up: • Sender's Email Name: enter the name of the email sender. • Sender's Email address: enter the sender's email address from which the email notification will be sent out. • Receiver's Email address: enter the receiver's email address.

  • Page 35: Logs

    Akuvox A02 Access Control Terminal Admin Guide 14 Logs 14.1 Access Log If you want to search and check on door access history, you can search and check the door logs on the device web Status > Access Log interface.

  • Page 36: Debug

    And the remote server address will be provided by Akuvox technical support. 15.2 Remote Debug Server You can set up a remote debug server so that Akuvox technical team will be able to obtain the log remotely for debugging. To configure the server, go to System > Maintenance>...

  • Page 37: Pcap For Debugging

    • Port: type in the remote debug server port. 15.3 PCAP for Debugging PCAP in A02 access control terminal is used to capture the data package going in and out of the devices for debugging and troubleshooting purposes. You can set up the PCAP on the device web System >...
  • Page 38 Akuvox A02 Access Control Terminal Admin Guide • PCAP Auto Refresh Enabled: select Enable or Disable to turn on or turn off the PCAP auto fresh function. If you set it as Enable then the PCAP will continue to capture data packets even after the data packets reached their 50M maximum in capacity.

  • Page 39: Firmware Upgrade

    Akuvox A02 Access Control Terminal Admin Guide 16 Firmware Upgrade Firmware of different versions for A02 access control terminal can be upgraded on the device web System > Upgrade interface. Note • Firmware files should be in .rom format for upgrade.

  • Page 40: Backup

    Akuvox A02 Access Control Terminal Admin Guide 17 Backup Configuration files can be imported to or exported out of the device to your local PC on the device web System > Maintenance > Others interface if needed. www.akuvox.com...

  • Page 41: Auto-Provisioning

    Akuvox A02 Access Control Terminal Admin Guide 18 Auto-provisioning Configurations and upgrading on A02 access control terminal can be done on the web interfaceviaone-timeauto-provisioningandscheduled auto-provisioningvia configuration files, thus saving you from setting up configurations needed one by one manually on the access control terminal.

  • Page 42: Configuration Files For Auto-Provisioning

    18.3 AutoP Schedule Akuvox provides you with different Autop methods that enable the access control terminal to perform provisioning for itself in a specific time according to your schedule. To configure the configuration on web System > Auto Provisioning > Automatic Autop interface.

  • Page 43: Dhcp Provisioning Configuration

    Akuvox A02 Access Control Terminal Admin Guide Parameter Set-up: • Power On: select Power on, if you want the device to perform Autop every time it boots up. • Repeatedly: select Repeatedly, if you want the device to perform Autop according to the schedule you set up.
  • Page 44 Akuvox A02 Access Control Terminal Admin Guide Note • The custom Option type must be a string. The value is the URL of the TFTP server. Parameter Set-up: • Custom Option: enter the DHCP code that matched the corresponding URL so that the device will find the configuration file server for the configuration or upgrading.

  • Page 45: Static Provisioning Configuration

    Akuvox A02 Access Control Terminal Admin Guide does not need to specify this. To make it work, you need to configure the DHCP server for option 43 with the updated server URL in it. Note • The general configuration file for the in-batch provisioning is with the format r0000000000xx.cfg, taking A01 as an example, r000000000101.cfg (10...
  • Page 46 Akuvox A02 Access Control Terminal Admin Guide • User Name: set up a user name if the server needs a user name to be accessed otherwise leave it blank. • Password: set up a password if the server needs a password to be accessed otherwise leave it blank.

  • Page 47: Integration With Third Party Device

    19 Integration with Third Party Device 19.1 Integration via Wiegand If you want to integrate the A02 access control terminal with the third-party devices via Wiegand, you can configure the Wiegand on the web Device > Wiegand interface. Parameter Set-up: •...

  • Page 48: Integration Via Http Api

    19.2 Integration via HTTP API HTTP API is designed to achieve a network-based integration between the third-party device with the Akuvox intercom device. You can configure the HTTP API function on the web Setting > HTTP API interface for the integration.

  • Page 49: Action Url

    Akuvox A02 Access Control Terminal Admin Guide 19.4 Action URL A02 allows you to set up specific HTTP URL commands that will be sent to the HTTP server for the predefined actions. Relevant actions will be initiated if there occurs any changes in the relay status, input status, PIN code, and RF card access for security purpose.
  • Page 50 Akuvox A02 Access Control Terminal Admin Guide Http://server ip/ Input Closed $input1status inputclose=$input1status Http://server ip/ Valid Code Entered $code validcode=$code Http://server ip/ Invalid Code Entered $code invalidcode=$code Http://server ip/ Valid Card Entered $card_sn validcard=$card_sn Http://server ip/ Invalid Car Entered $card_sn...

  • Page 51: Password Modification

    Akuvox A02 Access Control Terminal Admin Guide 20 Password Modification 20.1 Modify the Password On the device web interface, you can set and change passwords for accessing the web System > Security > Web Password Modify interface. In addition, you can also select the user role when setting passwords.

  • Page 52: System Reboot And Reset

    Akuvox A02 Access Control Terminal Admin Guide 21 System Reboot and Reset 21.1 Reboot If you want to restart the device, you can operate it on the device web System > Upgrade > Basic interface as well. Moreover, you can set up schedule for the device to be restarted.
  • Page 53 Akuvox A02 Access Control Terminal Admin Guide www.akuvox.com...

  • Page 54: Abbreviations

    Akuvox A02 Access Control Terminal Admin Guide 22 Abbreviations ACS: Auto Configuration Server Auto: Automatically AEC: Configurable Acoustic and Line Echo Cancelers ACD: Automatic Call Distribution Autop: Automatic Provisioning AES: Advanced Encryption Standard BLF: Busy Lamp Field COM: Common CPE: Customer Premise Equipment...
  • Page 55 Akuvox A02 Access Control Terminal Admin Guide PCMA: Pulse Code Modulation A-Law PCMU: Pulse Code Modulation µ-Law PCAP: Packet Capture PNP: Plug and Play RFID: Radio Frequency Identification RTP: Real-time Transport Protocol RTSP: Real Time Streaming Protocol MPEG: Moving Picture Experts Group...

  • Page 56: Faq

    23 FAQ Q1: How to obtain the IP address of the access control terminal? A1: Using Akuvox IP Scanner to search Akuvox devices in the same LAN network. Q2: What is the supported temperature range for A01? A2: Working Temperature: -20°C ~ +55°C Storage Temperature: -30°C ~ +70°C...

  • Page 57: Contact Us

    Akuvox A02 Access Control Terminal Admin Guide 24 Contact Us For more information about the product, please visit us at www.akuvox.com or feel free to contact us by Sales email: sales@akuvox.com Technical support email: support@akuvox.com Telephone: +86-592-2133061 ext.7694/8162 We highly appreciate your feedback about our products.
