Unpacking
Before you begin using the device, please check the version you got and ensure that the following items are included in the
shipped box:
A092 x1
ST4x20 crosshead screw x3
M3x5 crosshead screw x3
Wire x9
2x9-PIN terminal block x 2
Quick Guide
Wall-mounting template x1
Silicone pad (for wire) x2
Wire fastener x3
Cable tie x5
Plastic wall anchor x3
Silicon pad (for power supply) X1
Cable gland x1
2x6-PIN terminal block x 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Akuvox A092
Summary of Contents for Akuvox A092
- Page 1 Unpacking Before you begin using the device, please check the version you got and ensure that the following items are included in the shipped box: A092 x1 Plastic wall anchor x3 Wall-mounting template x1 Silicon pad (for power supply) X1...
- Page 2 A092 Product Overview Aircircuit-Breaker SNMPS Independent Relay Temper Proof Sensor Lock Backup Battery Bracket Status Indicator Main Board...
- Page 3 Installation Stick the wall-mounting template on the wall where the device needs to be Insert plastic wall Fix A092 with three ST4x20 anchors into the holes. installed. According to the screw hole crosshead screws on the wall. position on the template, use an electric drill to drill the hole with a diameter of 6mm and a depth of 25mm.
- Page 4 Connect the provided wire as plate and M3X5 crohsshead shown in the figure, then use screw to fix it. M3X5 crosshead screw and wire fastener to fix the wire on the A092. The installation is done, and please lock the cover. Then remove...
- Page 5 A092 Device Wiring...
- Page 6 A092 Configuration 1. While A092 starts up normally, click Search key in the IP Scanner tool to search the IP address. (Please consult Akuvox Technical Team for IP Scanner tool). 2. Access the Web UI: Type the IP address into browser to configure the device.
- Page 7 Notice Information Information contained in this document is believed to be accurate and reliable at the time of printing. This document is subject to change without notice, any update to this document can be viewed on Akuvox’ s website: http://www.akuvox.com...
