Hillsdale Furniture 1027-650 Assembly Instructions

Examine all packaging material for small parts that may have come loose during shipment. Periodic checks are recommended to insure that all
components are in proper position, tight and free from damage. Keep this assembly instruction for future reference. Adult assembly is required.
The product of Hillsdale Furniture, LLC is designed for residential use only. Customer Service Phone Number: 502-562-0000

HARDWARE LIST

A (6) M8*30mm Allen Bolts
B (6) M4*30mm Screws
C (1) Ø5 Allen Wrench
D (6) Adjustable Feet

PARTS LIST

E (3) Slats
F (2) Side Rails
G (6) Support Legs

STEP 1

Attach the Adjustable Feet (D) to the
Support Legs (G) by screwing them into
place. See Figure 1.

STEP 2

Next attach the Support Legs (G) to the Slats
(E) by using 1 Allen Bolt (A) from the top of
each slat. See Figure 2.

STEP 3

Finally attach the Slats (E) to the Side Rails (F)
by using 1 Screw (B) per side. See Figure 3.
CARE & MAINTENANCE: The touch of a soft cloth is all the maintenance the finish will ever need. Please do not use harsh or abrasive cleaners for polishing,
as they may cause damage to the finish. Periodic checks are recommended to make sure that all bolts, screws and nuts are securely tightened.
UNIVERSAL KING SIDE RAILS & SLATS
Model #1027-650 / 1554-650 / 1566-650 / 1638-650 / 1908-650
Model #1721-650 / 1722-650 / 1758-650 / 1118-650 / 1168-650 / 1801-650
PART QTY
A
C
F
FIGURE 1
G
D
E
HARDWARE
6
1
F
E
E
A
FIGURE 2
G
Date: 07-01-2015
PART QTY HARDWARE
B 6
D 6
FIGURE 3
B
F
E
E
Page 1 of 1
