- Page 1 EN : Th is Dat asheet is pr esent ed by t he m anuf act ur er . Please v isit our websit e f or pr icing and av ailabilit y at w w w.hest or e.hu.
- Page 2 HANDHELD DIGITAL CLAMP MULTIMETER AX-C850 OPERATOR’S INSTRUCTION MANUAL...
- Page 3 Safety Information To avoid possible electric shock or personal injury: • Never apply more than 30V between any two jacks, or between any jack and earth ground. • Make sure the battery door is closed and latched before you operate the calibrator. •...
- Page 4 Admit excitation current only apply on simulate mode. The admit excitation current could be marked on the OHM meter or RTD meter which was connected to the calibrator. Admit excitation current: 0.2mA Max input voltage: 30V Measure (input)/Simulate (output)RTD specification Mode Range Accuracy...
- Page 5 General Specifications: Maximum voltage applied between any jack and earth ground or between any tow jack: 30V Resolution: RTD 0.1 Resistance: 0.01/0.1 Ω Storage temperature: C~60 Operating temperature: C~55 Operating altitude: 3000 meters maximum Temperature coefficient: ±0.01%/ C on 0 C~18 C and 28 C~50...
- Page 6 6. RTD mode key F key 8. Input/Output key 9. Increase more value key/wire mode select 10. Reduce more value key/wire mode select 11. Increase less value key 12. Reduce less value key 13. Low power indication 14. Output state indication 15.
- Page 7 RTD Simulate Press the power key , turn on the calibrator Press the input/output key , when on the output mode. Press the RTD mode key , on the measure type you want. Press the adjust value key , to let the value on your need. Put the RTD meter or Resistance meter on the input Jack.
- Page 8 Maintenance Cleaning Periodically wipe the case with a damp cloth and detergent; do not use abrasives or solvents. Calibration Calibrate your calibrator once a year to ensure that it performs according to its specifications. Replacing the Battery Please change the battery when the LCD indicates Turn off the power of the Calibrator, when you change the battery, and screw off the breechblock on the battery cabinet cover, then take off it and instead the fresh AAA 1.5.V battery.
