Axio MET AX-7600 Instructions Manual

Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

1. Safety instructions

AX-7600 is Class II laser product and accords with EN60825-1 safety standard. Failure to follow the instructions listed
below may cause personal injury.
•
Read and understand all instructions prior to any operation.
•
Do not remove any labels from the tool.
•
Do not operate the tool with the presence of flammable/explosive gases.
•
Do not operate the laser tool around children or allow children to operate the laser tool, failure to do so will injure
children's eyes.
•
Do not stare into the laser beam.
•
Do not project the laser beam directly into the eyes of others.
•
Do not set up the tool at eye level or operate the tool on or near a reflective surface, as the laser could be projected
into people's eyes.
•
Do not observe the laser beam by using optical tools such as binoculars and magnifying glass.
•
To avoid burning danger, remember that the reflective objects make the reading lower than their actual temperature.
DANGER
Class II Laser Product
Maximum Power Output< 1mW
Wavelength: 630-660nm
Do not stare into beam!
Avoid direct eye exposure!
This tool emits a laser radiation!
AX-7600

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AX-7600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Axio MET AX-7600

Summary of Contents for Axio MET AX-7600

  • Page 1: Safety Instructions

    AX-7600 1. Safety instructions AX-7600 is Class II laser product and accords with EN60825-1 safety standard. Failure to follow the instructions listed below may cause personal injury. • Read and understand all instructions prior to any operation. • Do not remove any labels from the tool.

  • Page 2: Product Overview

    2. Product overview 1. Color LED indication for mildew possibility 2. LCD screen 3. Unit switch + mute button 4. Mode switch + Emissivity switch+ power off 5. laser control 6. Environment parameters sensor part 7. Laser window 8. Infrared sensor 9.
  • Page 3 3. Illustration of display screen 1. Data hold; 2. Infrared scan icon; 3. Ambient temperature measurement mode 4. Dew point measurement mode 5. Environment temperature value 6. Infrared measurement icon 7. Infrared temperature value 8. Emissivity value 9. Low battery indication 10.

  • Page 4: Operating Instructions

    4. Operating Instructions Press the measuring trigger to power on, press again for IRT scan,release it to hold data. Press the MODE button to switch among AT, DP and RH. Hold the trigger then press MODE to adjust the emissivity 0.75, 0.85, 0.95; Long time holding the MODE to power off.

  • Page 5: Operation Notes

    Heat shock (by abrupt temperature changes, allow 30 minutes for unit to stabilize before use.); High temperature objects; 8. Technical specifications Product name: Multifunction Infrared Thermometer Model :AX-7600 Surface temperature measurement range:-50°C~+350°C(-58°F~662°F) Environment temperature measurement range: -10°C~+40°C(14°F~104°F) Relative humidity measurement range: 10%~90% Measurement accuracy: - For surface temperature;...
  • Page 6 Laser grade: Class II Laser type: 630~660nm,<1mW Power supply: 9V battery Continuous operating life time for battery:>6 hours Auto power off:1 minutes inactivity Operating temperature range: -10°C~+40°C(14°F~104°F) Operating humidity: 0~95%RH non-condensing Storage temperature: -20°C~70°C(-4°F~158°F),≤85%(w/o battery) Product dimension: 170mm×135mm×50mm Product weight: About 168g (w/o battery)
