Global Settings
Gate Source Power-On Commands
Determines which sources will trigger the Keyboard Gate and Contour Generators
External Gate
Sets gate source as EXT. V-TRIG input only
External and Local
Keys (No MIDI)
Sets gate source as both the local keyboard and the EXT. V-TRIG input —notes received via MIDI will not
trigger the contour generators
External and MIDI (No
Local Keys)
Sets gate source as both MIDI and the EXT. V-TRIG input —keys pressed on the keyboard will not trigger
the contour generators
External, MIDI, and
Local Keys (All)
Sets gate source as the local keyboard, MIDI input, and the EXT. V-TRIG input—this is the
default behavior
Velocity Control Voltage Range Power-On Commands
The voltage range of the Velocity control output can be doubled from five volts to ten volts in order to
accommodate different types of analog equipment.
Velocity CV Range = 5
Volts
Limits the Velocity CV range to 5 Volts
Velocity CV Range = 10
Volts
Expands the Velocity CV range to 10 Volts
Hold F2 + A2 while turning on the power.
Hold F2 + Bb2 while turning on the power.
Hold F2 + B2 while turning on the power.
Hold F2 + C3 while turning on the power.
Hold G0 + C#1 while turning on the power.
Hold G0 + D1 while turning on the power.
