Furniture of America CM7150D Assembly Instructions

For more information contact our team: service.ec@foagroup.com

ASSEMBLY RATING

The Assembly Rating is a 5-point system that

shows the degree of effort needed in

assembling a specific product (with 1 being

easy and 5 being difficult). For some

products, two persons are recommended.

EASY

CM7150D

DIFFICULT

Page 1 of 5

Tools Required For Assembly:

Allen Wrench

Philip Screwdriver

2 PERSONS RECOMMENDED

(Included)

(Not Included)

Rev: 18-11-27

Table of Contents

Do you have a question about the CM7150D and is the answer not in the manual?

Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7150D ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult).
Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 5...
Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 4pcs Bolt Ø5/16" x 3-1/2" Dresser #2 x 4pcs #B x 4pcs Bun Foot Lock Washer Ø5/16"...
Page 4 Align legs (#2) with washers (#D) to the dresser (#1), then secure by using bolts (#A) with washers (#B,C). Align and attach center leg (#3) to the dresser (#1), then adjust the leveler according to ground level. #A x 4pcs #B x 4pcs #C x 4pcs #D x 4pcs...
Page 5 Remove knobs from the inside then secure knobs to the outside. ASSEMBLY IS COMPLETED Page 5 of 5...
