For more information contact our team: service.ec@foagroup.com
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7150Q/EK/CK
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 9
(Included)
(Not Included)
REV: 17-11-28
Advertisement
Related Manuals for Furniture of America CM7150Q-EK
Summary of Contents for Furniture of America CM7150Q-EK
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7150Q/EK/CK ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 9...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 1pc Allen Wrench M4 Headboard #2 x 1pc #B x 10pcs % R O W Footboard #3 x 2pcs...
- Page 4 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #9 x 2pcs #I x 2pcs Center Rail Anti Slip Sheet #10 x 2pcs #J x 4pcs Screw #4 x 3/4"...
- Page 5 Prepare 4 bolts assembly by inserting lock washer (#F), washer (#G), then flat washer (#H) onto bolts (#B). Align support legs (#6) to the holes of the headboard (#1). Secure by using bolts (#B). #B x 4pcs #F x 4pcs #G x 4pcs #H x 4pcs Prepare 6 bolts assembly by inserting lock washer (#F), washer (#G), then flat...
- Page 6 Align center rail support (#12) to the holes of the footboard (#2). Secure by using bolts (#D). #D x 4pcs Attach anti slip sheet (#I) to the threaded bolts of the legs (#10). Align and attach legs (#10) to the holes of the footboard (#2). Secure by using screws (#K). #I x 2pcs #K x 2pcs Page 6 of 9...
- Page 7 Align side rails (#3R/L) to the holes of the legs (#10), then secure by using screws (#K). #K x 2pcs # 3R # 3L 1) Prepare 4 bolts assembly by inserting lock washer (#F), then flat washer (#G) onto bolts (#E). Secure side rails (#3R/L) to the holes of the footboard (#2) by using bolts (#E).
- Page 8 Secure headboard panel (#4) to the headboard (#1) by using screws (#J). #J x 4pcs # 3R # 3L Align slats (#8) to center rails (#9) and support legs (#11). Secure by using bolts (#D). Adjust leveler of the support legs (#11) according to ground level. #D x 6pcs Page 8 of 9...
- Page 9 Align slats to the side rails, then secure by using screws (#L). #L x 6pcs # 3R # 3L Align slats (#7) to the side rails, then secure by using screws (#L). #L x 22pcs # 3R # 3L Page 9 of 9...
