- Page 4 Prepare 8 bolts assembly by inserting washer (#G) onto bolts (#F). Align headboard legs (#2R/L) to the holes of the headboard (#1). Secure by using bolts (#F).
- Page 5 Attach dowels (#A) and threaded pins (#B) to the holes of the headboard (#1) and footboard (#3). Align side rails (#4) to the dowels (#A) and threaded pins (#B) of the headboard (#1) and footboard (#3). Secure by using half moon washer (#C) and hex nut (#D). Align slats (#5) to the side rails (#4), then secure by using screws (#E).
- Page 9 Prepare 8 bolts assembly by inserting washer (#G) onto bolts (#F). Align headboard legs (#2R/L) to the holes of the headboard (#1). Secure by using bolts (#F).
- Page 10 Attach dowels (#A) and threaded pins (#B) to the holes of the headboard (#1) and footboard (#3). Align side rails (#4) to the dowels (#A) and threaded pins (#B) of the headboard (#1) and footboard (#3). Secure by using half moon washer (#C) and hex nut (#D).
- Page 11 Align slats (#5) to the side rails (#4), then secure by using screws (#E).
- Page 15 Align casters (#D) to the holes of the left and right side panels (#3). Secure by using screws (#C). Attach dowels (#A) to each ends of the left and right side panels (#3). Align and attach left and right side panels (#3) to the dowel holes of the front panel (#1) and back panel (#2).
- Page 16 Align slats (#5) to the front and back panels (#1,2). Secure by using screws (#G). 2) Align bottom panel (#4) to the rest of the trundle. Secure by using screws (#G). 1) Align knobs (#F) to the holes of the front panel. Secure by using bolts (#E) from the inside.
