For more information contact our team: service.ec@foagroup.com
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7150Q/EK/CK
DIFFICULT
Page 1 of 10
Tools Required For Assembly:
Allen Wrench
Philip Screwdriver
2 PERSONS RECOMMENDED
(Included)
(Not Included)
Rev: 18-11-27
Advertisement
Related Manuals for Furniture of America CM7150Q
Summary of Contents for Furniture of America CM7150Q
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7150Q/EK/CK ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 10...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 1pc Headboard Allen Wrench M4 #2 x 1pc #B x 10pcs Footboard Bolt Ø1/4"...
- Page 4 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #10 x 2pcs #J x 4pcs Screw M3 x 5/8" Center Rail #11 x 2pcs #K x 4pcs Screw M4 x 1"...
- Page 5 Align HB support rails (#7) to the headboard (#1), then secure by using bolts (#B) with washers (#F,H). #B x 4pcs #F x 4pcs #H x 4pcs Align headboard (#1) to the ear panels (#5R/L), then secure by using bolts (#B) with washers (#F,H). #B x 6pcs #F x 6pcs #H x 6pcs...
- Page 6 Align center rail supports (#13) to the footboard (#2), then secure by using bolts (#D) with washers (#F,G). #D x 4pcs #F x 4pcs #G x 4pcs Align legs (#11) with washer (#I) to the footboard (#2), then secure by using screws (#K) #I x 2pcs #K x 2pcs Secure only the hole...
- Page 7 Align side rails (#3R/L) to the footboard (#2), then secure by using bolts (#E) with washers (#F,G). #E x 4pcs #F x 4pcs #G x 4pcs Secure the legs (#11) to the side rails (#3R/L) by using screws (#K). #K x 2pcs Page 7 of 10...
- Page 8 Align headboard ears (#5R/L) to side rails (#3R/L), then secure by using bolts (#C) with washers (#F,H). #C x 4pcs #F x 4pcs #H x 4pcs #J x 4pcs Align HB panel (#4) to the headboard, then secure by using screws (#J). Page 8 of 10...
- Page 9 Align support bars (#6) to the bottom of the side rails (#3R/L), then secure by using screws (#M). Secure side rails (#3R/L) to HB ears (#5R/L) by using bolts (#C) with washers (#F,H). #C x 4pcs #F x 4pcs #H x 4pcs #M x 6pcs #D x 6pcs #F x 6pcs...
- Page 10 Secure slats (#9) to side rails (#3R/L) by using screws (#L). #L x 8pcs Align slats (#8) to the side rails (#3R/L), then secure by using screws (#L). #L x 22pcs Page 10 of 10...
