teel 2P087C Operating Instructions & Parts Manual

Operating Instructions & Parts Manual
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
®
Teel Mini Submersible
Sump Pump
Description
The Teel mini submersible sump pump is used for water removal in home and
industrial applications. Used for sump service and dewatering. Starts immediately
and runs continually, when cord is plugged in. Constructed of hi-impact corrosion
resistant plastic. Screened inlet prevents large solids from entering pump. Will
pump down to 3/16". For operation over 15 minutes continuously, pump should be
immersed a minimum of 4" to provide proper motor cooling.
NOTE: This unit is not designed for applications involving salt water or brine!
Specifications
Power supply required ................................................................................ 115V, 60Hz.
Motor ..................................................................................................... 1/6 HP, oil filled
Motor duty.................................................................................................. Continuous*
Thermal protector.......................................................................................... Automatic
Liquid temp. range...................................................................................... 40°F to 70°F
Operating position ............................................................................................. Vertical
Circuit requirement (min.) ................................................................................. 15 AMP
Max. Load Amps ......................................................................................................... 5.0
Weight .................................................................................................................... 8 Lbs.
Dimensions (overall) ....................................................................................... 9"H x 6"D
Construction:
Motor top............................................................................................................. Nylon
Pump body & base............................................................................................ Polypro
Incased motor ......................................................................................................... Zinc
Shaft.......................................................................................................... 416 Stainless
Lip seal & "O" ring ................................................................................ Buna-N Nitrile
Operating depth (water level)
Beginning min ........................................................................................................ 1/2"
Ending max........................................................................................................... 3/16"
Power cord set .................................................................................. Vinyl, 8 ft. 3-prong
Discharge .............................................................................................................. 1" NPT
(*) For continuous duty pump must be submerged in a minimum of 4" of water.
Performance
3 ft. 5 ft.
1140 1050
Ratings shown are for 1" pipe. Flow rate is reduced when using garden hose.
Form 5S2415
GPH at Total Head in Feet
10 ft. 15 ft.
840 480
© 1996 W.W. Grainger, Inc.
Printed in U.S.A.
08210
0796/227/VCPVP
General Safety Information
Electrically powered sump pumps
normally give many years of trouble-
free service when correctly installed,
maintained, and used. However,
unusual circumstances (interruption of
power to the pump, dirt/debris in the
sump, flooding that exceeds the pump's
capacity, electrical or mechanical failure
in the pump, etc.) may prevent your
pump from functioning normally. To
prevent possible water damage due to
flooding, consult your dealer about
installing a secondary sump pump, a DC
backup sump pump, and/or a high
water alarm. See the "Troubleshooting
Chart" in this manual for information
about common sump pump problems
and remedies. For more information,
see your dealer.
1. Know the pump application,
limitations, and potential hazards.
Pump water only with this pump.
atmospheres. Pump is not explosion
proof.
2. Disconnect power before servicing.
3. Release all pressure within the
system before servicing any
component.
4. Drain all water from the system
before servicing.
5. Secure the discharge line before
18.5 ft.
starting the pump. An unsecured
Shut-off
discharge line will whip, possibly
causing personal injury and/or
property damage.
6. Check hoses for weak or worn
condition before each use, making
certain that all connections are
secure.
2P087C
E
N
G
L
I
S
H
E
S
P
A
Ñ
O
L
