teel 4RJ58 Operating Instructions & Parts Manual

Operating Instructions & Parts Manual
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
®
Teel High Head Straight
Centrifugal Pumps
Description
Teel general purpose centrifugal pumps (Model Nos. 4RH33, 4RH34, and 4RJ58 thru
4RJ81) are for use in water systems and sprinkling for homes, farms, and industry.
Pump motors range from 115/230V single phase to 208-230/460V three phase. 1/2
to 3 HP high head models deliver from 80' to 148' of head with capacities ranging
from 19 to 92 GPM. Pumps have suction capability of 25 ft. when installed with
foot valve.
Body and seal plate are close-grained cast iron. Impellers for Models 4RJ70 thru
4RJ81 are Noryl, abrasion resistant for normal applications with working
temperatures to 140°F (60°C). Impellers for Models 4RH33, 4RH34, and 4RJ58 thru
4RJ69 are brass and rated for temperatures to 225°F (107°C). Drain port is provided
for easy winterizing.
Unpacking and Inspection
Handle with care. Check items received against packing list to be sure that all
equipment has been received. Inspect for shipping damage. If found, file claim with
carrier immediately.
General Safety Information
READ AND FOLLOW
SAFETY INSTRUCTIONS!
This is the safety alert symbol.
When you see this symbol on your
pump or in this manual, look for one of
the following signal words and be alert
to the potential for personal injury.
Warns about
hazards
that will cause serious personal injury,
death, or major property damage if
ignored.
Warns about
hazards that can
cause serious personal injury, death, or
major property damage if ignored.
Warns about
hazards that will or
can cause minor personal injury or
property damage if ignored.
NOTE: Indicates special instructions
which are important but not related to
hazards.
Form 5S4178
Carefully read and follow all safety
instructions in this manual and on
pump.
Keep safety labels in good condition.
Replace missing or damaged safety
labels.
ELECTRICAL SAFETY
Hazardous voltage.
Can shock, burn, or
cause death. Ground pump before
connecting to power supply. Disconnect
power before working on pump, motor,
or tank.
Capacitor voltage
may be hazardous.
To discharge motor capacitor, hold
insulated handle screwdriver BY THE
HANDLE and short capacitor terminals
together. Do not touch metal
screwdriver blade or capacitor terminals.
If in doubt, consult a qualified electrician.
Wire motor for correct voltage. See
"Electrical" section of this manual
and motor nameplate.
Printed in U.S.A.
09319
0600/226/E3
4RH33, 4RH34 and 4RJ58 thru 4RJ81
Ground motor before connecting to
power supply.
Meet United States National Electri-
cal Code, Canadian Electrical Code,
and local codes for all wiring.
Follow wiring instructions in this
manual when connecting motor to
power lines.
relief valve in discharge pipe. Release all
pressure on system before working on
any component.
Modern motors are designed to operate
at high temperatures. To avoid burns
when servicing pump, allow it to cool for
20 minutes after shut-down before
handling.
Do not allow pump or any system com-
ponent to freeze. To do so will void
warranty.
Pump water only with this pump.
Periodically inspect pump and system
components.
Wear safety glasses at all times when
working on pumps.
Keep work area clean, uncluttered, and
properly lighted; store properly all
unused tools and equipment.
Keep visitors at a safe distance from the
work areas.
booster pump unless relief valve capable
of passing full pump flow at 75 psi is
installed.
