teel 4RK45A Operating Instructions & Parts Manual

Operating Instructions & Parts Manual
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Teel Submersible Effluent and ®
Sewage/Solids Handling Pumps
Description
Teel submersible effluent pumps, Model Numbers 4RK62A and 4RK63A, and
sewage/solids handling pumps, Model Numbers 4RK45A, 4RK46A, 4RK47A, 4RK48A
and 4RK49A are used for sewage, effluent and wastewater removal, sump drainage,
liquid transfer systems, circulation, dewatering, and flood control. Pump motors are
rated for continuous duty** and range from 230V single phase with automatic
thermal reset to 230/460V three phase. 60 hertz, oil filled, 1 HP, 1
deliver from 38 to 85 feet of head with capacities ranging from 20 to 250 GPM.
Volute and semi-open impeller are close grained cast iron. Dual shaft seal,
extended pump out vanes and seal plate barrier provide greater seal protection.
Effluent pumps have 3/4" spherical solids handling capability. Sewage/solids
handling pumps handle 2" spherical solids. Stainless steel hardware for easy
disassembly after extended use. All pumps are manually operated except Model
4RK62A, which has an automatic float switch. Switch ON setting is 18
OFF setting is 9 1 ⁄ ".
2
** For continuous duty, fully submerge in liquid at maximum 105° F (41° C).
Maximum temperature 130° F (69° C) for intermittent duty.
Unpacking and Inspection
Handle with care. Check items received against packing list to be sure that all
equipment has been received. Inspect for shipping damage. If found, file claim
with carrier immediately.
Specifications
Volts
@
Models HP 60 Hz.
4RK45A 1 230
4RK46A 1 230/460*
4RK47A 1 ⁄ 230
1
2
4RK48A 1 1 ⁄ 230/460*
2
4RK49A 2 230
4RK62A 2 230
4RK63A 2 230/460*
(*) These models are pre-wired at factory for 230V.
Dimensions
Models Base
4RK45A Cast iron
4RK46A Cast iron
4RK47A Cast iron
4RK48A Cast iron
4RK49A Cast iron
4RK62A Cast iron
4RK63A Cast iron
Form 5S4184
4RK45A, 4RK46A, 4RK47A, 4RK48A, 4RK49A, 4RK62A and 4RK63A
Motor Indivdual Branch
Full Load Circuit Required
Phase Amps
1 8.5
3 8.5/4.1
1 12.0
3 9.0/4.7
1 13.0
1 9.3
3 7.5/3.8
Pump Materials
Housing Cover
Cast iron Cast iron
Cast iron Cast iron
Cast iron Cast iron
Cast iron Cast iron
Cast iron Cast iron
Cast iron Cast iron
Cast iron Cast iron
Printed in U.S.A.
09319
1202/258/VCPVP
1 ⁄ HP, and 2HP models
2
1 ⁄ " and switch
2
Maximum
Fluid
(Amps) Temperature
15 130° F
15/15 130°
15 130°
15/15 130°
15 130°
15 130°
15/15 130°
Dimensions
Impeller Height
Cast iron 20 ⁄ "
1
2
Cast iron 20 1 ⁄
2
Cast iron 20 1 ⁄
2
Cast iron 20 1 ⁄
2
Cast iron 20 1 ⁄
2
Cast iron 18 ⁄
1
2
Cast iron 18 ⁄
1
2
General Safety Information
READ AND FOLLOW
SAFETY INSTRUCTIONS!
This is the safety alert symbol.
When you see this symbol on your
pump or in this manual, look for one of
the following signal words and be alert
to the potential for personal injury.
Warns about
hazards
that will cause serious personal injury,
death, or major property damage if
ignored.
Warns about
hazards that can
cause serious personal injury, death, or
major property damage if ignored.
Warns about
hazards that will or
can cause minor personal injury or
property damage if ignored.
NOTE: Indicates special instructions
which are important but not related to
hazards.
Service
Sewage/solids handling
Sewage/solids handling
Sewage/solids handling
Sewage/solids handling
Sewage/solids handling
Effluent
Effluent
Cord
Diameter Length
16 ⁄ " 20'
7
8
16 7 ⁄ 20
8
16 7 ⁄ 20
8
16 7 ⁄ 20
8
16 7 ⁄ 20
8
16 ⁄ 20
7
8
16 ⁄ 20
7
8
E
N
G
L
I
S
H
E
S
P
A
Ñ
O
L
Discharge
NPT (in.)
3"
3
F
3
R
3
3
A
2
N
2
Ç
A
I
S
Weight
117 lbs.
121
122
121
122
120
120
®
