teel 4RJ19 Operating Instructions & Parts Manual

Operating Instructions & Parts Manual
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Teel Residential ®
Submersible Sump Pumps
Description
This Submersible Sump Pump is designed for home use in draining flooded
excavations, construction sites, and basements. The 115V, 60 Hz, shaded-pole
motors have automatic overload protection, and are oil filled and sealed for cooler
running. Bearings on motor shaft never need lubrication. Model Numbers 4RJ19
and 4RJ21 are manually controlled. Model Numbers 4RJ20, 4RJ22, and 4RJ23 are
equipped with an automatic tethered float switch. Unit is equipped with either an
8, 20, or 25 ft., 3-prong grounding-type power cord. See "Specifications," below.
Models have cast iron construction with a bottom inlet screen. Model 4RJ23 has a
fiberglass reinforced polypropylene base. Model 4RJ19 includes a garden hose
adapter. Models 4RJ19 and 4RJ20 have a Noryl impeller. Models 4RJ21, 4RJ22 and
4RJ23 have a fiberglass reinforced polypropylene impeller. These pumps are for
use with nonflammable liquids compatible with construction materials only.

Unpacking and Inspection

Handle with care. Check items received
against packing list to be sure that all
equipment has been received. Inspect
for shipping damage. If found, file
claim with carrier immediately.
General Safety Information
READ AND FOLLOW
SAFETY INSTRUCTIONS!
This is the safety alert symbol.
When you see this symbol on your
pump or in this manual, look for one of
the following signal words and be alert
to the potential for personal injury.
Specifications
Motor
Full Load
Modeles HP Amps
4RJ19 3/10 9.0
4RJ20 3/10 9.0
4RJ21 4/10 13.0
4RJ22 4/10 13.0
4RJ23 1/2 12.0
Form 5S4182
that will cause serious personal injury,
death or major property damage if
ignored.
cause serious personal injury, death or
major property damage if ignored.
can cause minor personal injury or
property damage if ignored.
NOTE: Indicates special instructions
which are important but not related to
hazards.
Discharge
Height Diameter NPT
11 3 ⁄ " 12 5 ⁄ " 1
8 8
11 3 ⁄ 12 5 ⁄ 1
8 8
11 ⁄ 12 ⁄ 1
3 5
8 8
11 3 ⁄ 12 5 ⁄ 1
8 8
11 1 ⁄ 14 1
2
Printed in U.S.A.
09319
0801/133/VCPVP
4RJ19, 4RJ20, 4RJ21, 4RJ22 and 4RJ23
Electrically powered sump pumps
normally give many years of trouble-
free service when correctly installed,
maintained, and used. However,
unusual circumstances (interruption of
power to the pump, dirt/debris in the
sump, flooding that exceeds the
pump's capacity, electrical or
mechanical failure in the pump, etc.)
may prevent your pump from
functioning normally. To prevent
possible water damage due to
flooding, consult your dealer about
installing a secondary sump pump, a
DC backup sump pump, and/or a high
water alarm. See the "Troubleshooting
Warns about
Chart" in this manual for information
hazards
about common sump pump problems
and remedies. For more information,
see your dealer or call customer
service.
Warns about
Know the pump application,
hazards that can
limitations, and potential hazards.
Disconnect power before servicing.
Warns about
Release all pressure within system
hazards that will or
before servicing any component.
Drain all water from system before
servicing.
Maximum
Cord Liquid
Length Temperature
1 ⁄ " 8' 77° F
2
1 ⁄ 8 77°
2
⁄ 20 77°
1
2
1 ⁄ 8 77°
2
1 ⁄ 25 130°
2
Switch Switch
Shipping On Off
Weight Point Point
17 lbs. – –
18 13" 5"
18 – –
19 13 5
34 12 1 ⁄ 3 1 ⁄
2 2
