Summary of Contents for MacroMedics DSPS-Prominent
- Page 1 MANUAL 113000 Instructions for use English Instructions S O L U T I O N S I N R A D I O T H E R A P Y MacroMedics DSPS-Prominent ™ ® MacroMedics BV Oostbaan 670 2841ML Moordrecht...
- Page 2 Manual DSPS-Prominent Instructions for use ™ S O L U T I O N S I N R A D I O T H E R A P Y [ This page is intentionally left blank ] MacroMedics ® 19092022V2IFU113000...
-
Page 3: Table Of Contents
Manual DSPS-Prominent Instructions for use ™ S O L U T I O N S I N R A D I O T H E R A P Y Table of Contents 1. Warnings 2. MRI Safety Information 3. Intended Use/Indications for Use 4. -
Page 4: Warnings
Manual DSPS-Prominent Instructions for use ™ S O L U T I O N S I N R A D I O T H E R A P Y 1. Warnings • Inspect the device thoroughly before use. Do not use the device if damaged or incomplete. -
Page 5: Baseplate Set-Up
For use in MR, use the glass fiber, MR Safe 3-Pin couchstrip. Position the DSPS-Prominent above the couchtop. Then, align the slots at the bottom of the baseplate with the two couchstrips and carefully place the baseplate on the couchstrips. - Page 6 If the mask is too warm, let it cool down before placing it on the patient. Ask the patient to sit up. Place the mask onto the DSPS-Prominent cradle so that the pins at the bottom of the black frame fall into the designated holes of the cradle.
- Page 7 When using a Waterbath (of min. internal dimensions, in mm: 665w x 575d x 80h - we recommend using the MacroMedics MacroBath 4) to heat the mask, set the water temperature between 68°C and 70°C (154.4°F and 158°F). Leave the mask in the water for approximately 1 to 2 minutes until it becomes sufficiently pliable.
- Page 8 Manual DSPS-Prominent Instructions for use ™ S O L U T I O N S I N R A D I O T H E R A P Y Push the white frame slowly towards the black frame. Once both frames touch, secure the mask in place by pushing the sliding lock pawls into locked position.
- Page 9 Manual DSPS-Prominent Instructions for use ™ S O L U T I O N S I N R A D I O T H E R A P Y REMOVING THE MASK Unlock the two rotatable lock pawls at both sides of the frame.
-
Page 10: Cleaning, Storage And Disposal
Defects, malfunctions or failures caused by nature, misuse, abuse and unauthorised alteration or repair are not warranted. This warranty is limited to the repair and/or replacement at the sole discretion of MacroMedics. 8. Notices Any serious incident that has occurred in relation to the device should be reported to the manufacturer and the competent authority of the Member State in which the user or patient is established. -
Page 11: Glossary Of Symbols
Manual DSPS-Prominent Instructions for use ™ S O L U T I O N S I N R A D I O T H E R A P Y 9. Glossary of Symbols Symbol Symbol Name Description of Symbol EC Declaration of Conformity by Manufacturer. - Page 12 S O L U T I O N S I N R A D I O T H E R A P Y MacroMedics BV Oostbaan 670 2841ML Moordrecht The Netherlands +31(0)182 38 97 77 info@macromedics.com www.macromedics.com (Visit www.macromedics.com for a digital copy of this manual)
