- Page 1 MANUAL 132100 Instructions for use English Instructions MacroMedics LEX-Ultra ® MacroMedics BV Oostbaan 670 2841ML Moordrecht The Netherlands +31(0)182 389 777 info@macromedics.com www.macromedics.com...
- Page 2 Manual LEX-Ultra Instructions for use Table of Contents 1. Warnings 2. MRI Safety Information 3. Intended Use 4. Installation Instructions 5. Cleaning, Storage and Disposal 6. Warranty 7. Notices 8. Glossary of Symbols 26042021V7IFU132100 MacroMedics ®...
- Page 3 The following devices are MR unsafe: • 132100 LEX Ultra MR SAFE The following devices are MR safe: • 132150 LEX-Ultra MR 3. Intended Use Positioning of the patient during radiotherapy and radiodiagnostics, including MR where indicated. 26042021V7IFU132100 MacroMedics ®...
- Page 4 2x Countersunk M6x20 Polyamide screws. PLACE THE LEX-ULTRA Carefully align the LEX-Ultra with the CouchStrips and gently slot into place. CHANGING THE TILTING POSITION OF THE LEG SUPPORT Open the locking mechanism by pulling the coverplate towards caudal direction, allowing the pins of the leg supports to fall into the indents in the base.
- Page 5 Manual LEX-Ultra Instructions for use LOCKING THE LEG SUPPORTS IN THE CORRECT POSITION Close the locking mechanism by pushing the coverplate towards cranial direction. REMOVING THE MIDDLE BLOCK (OPTIONAL) Remove the middle block by pushing the coverplate towards cranial direction, unlocking the locking mechanism, and then lift the middle block.
- Page 6 Defects, malfunctions or failures caused by nature, misuse, abuse and unauthorised alteration or repair are not warranted. This warranty is limited to the repair and/or replacement at the sole discretion of MacroMedics. 7. Notices Any serious incident that has occurred in relation to the device should be reported to the manufacturer and the competent authority of the Member State in which the user or patient is established.
- Page 7 Manual LEX-Ultra Instructions for use 8. Glossary of Symbols Symbol Symbol Name Description of Symbol EC declaration of conformity by manufacturer. European Conformity Indicates the medical device manufacturer. Manufacturer Indicates the manufacturer’s catalogue number so that the Catalogue Number medical device can be identified.
- Page 8 MacroMedics BV Oostbaan 670 2841ML Moordrecht The Netherlands +31(0)182 389 777 info@macromedics.com www.macromedics.com (Visit www.macromedics.com for a digital copy of this manual)
