- Page 1 MANUAL 122500 Instructions for use English Instructions MacroMedics BreastBoards & ThoraxSupports ® MacroMedics BV Oostbaan 670 2841ML Moordrecht The Netherlands +31(0)182-389777 info@macromedics.com www.macromedics.com...
- Page 2 Manual BreastBoards & ThoraxSupports Instructions for use [ This page is intentionally left blank ] 02082021V11IFU122500 MacroMedics ®...
-
Page 3: Table Of Contents
Manual BreastBoards & ThoraxSupports Instructions for use Table of Contents 1. Warnings 2. MRI Safety Information 3. Intended Use 4. Installation Instructions 5. Cleaning, Storage and Disposal 6. Warranty 7. Notices 8. Glossary of Symbols 02082021V11IFU122500 MacroMedics ®... -
Page 4: Warnings
• 122380 Profiles LB1, set/10 • 122390 Profiles LB1, set/2 • 122520 WedgeThoraxSupport™ • 122540 HighBridgeSupp. TS/MBLX • 122610 ThoraxSupport™ complete • 122650 ThoraxSupport™ short • 122670 90D ArmSupports TS • 122730 Handpoles MBLX-LB1 • 122760 Handpoles with armcup •... -
Page 5: Intended Use
BreastBoards & ThoraxSupports Instructions for use MR CONDITIONAL The following devices are MR conditional: • 122750 BreastBoard LX™ MRC • 122150 ThoraxSupport™, MRC • 122660 ThoraxSupport™short MRC • 122740 Wrist support for handpoles set/2 • 174590 OmniBoard™ BTM RE MRC •... -
Page 6: Installation Instructions
OmniBoard/FlexBoard and the BreastBoard will lock itself. Fix the BreastBoard at an angle using the Angled plates. The images above show the attachment of the BreastBoard EX to the FleXBoard. The procedure is the same for attaching the BreastBoard Modules to the OmniBoard. 02082021V11IFU122500 MacroMedics ®... - Page 7 (For the usage in a MR environment, use the glass fiber, MR-Safe 3-Pin CouchStrip). Position the BreastBoard or ThoraxSupport above the Couchtop, align the slots at the bottom of the module with the CouchStrips and carefully place it on the Couchtop.
- Page 8 The Armsupports The armsupports can be adjusted in one direction. The Upper Armsupports The upper arm supports can be adjusted in three directions with pushpins. The Cranial Armsupports The Cranial Arm Supports can be adjusted in two directions. 02082021V11IFU122500 MacroMedics ®...
- Page 9 Installation of the EagleBoard 2 on the BreastBoard EX Position the EagleBoard 2 above the BreastBoard EX, align its holes at the bottom with the knobs on the BreastBoard EX and place it carefully on the BreastBoard. 02082021V11IFU122500 MacroMedics ®...
- Page 10 Slide the EagleBoard 2 towards the caudal side and lock it by turning the lock knobs counterclockwise. Turn the lock knobs back in clockwise direction to loosen. For adjustment of the EagleBoard 2 in longitudinal direction, loosen both of the grip knobs at the dorsal side of the BreastBoard EX. 02082021V11IFU122500 MacroMedics ®...
- Page 11 Turn the grip knobs clockwise to lock the EagleBoard 2 on the desired indexed position. Align the M-Grip with the rails on the EagleBoard 2. Push the white lock knobs on the M-Grip and slide it onto the rails. 02082021V11IFU122500 MacroMedics ®...
- Page 12 BreastBoards & ThoraxSupports Instructions for use Place the M-Grip on the desired indexed position and release the lock knobs to fix the M-Grip to the rails of the OmniBoard EX. Place the HeadSupport in the HeadSupport adaptor. 02082021V11IFU122500 MacroMedics ®...
-
Page 13: Cleaning, Storage And Disposal
Defects, malfunctions or failures caused by nature, misuse, abuse and unauthorised alteration or repair are not warranted. This warranty is limited to the repair and/or replacement at the sole discretion of MacroMedics. 7. Notices Any serious incident that has occurred in relation to the device should be reported to the manufacturer and the competent authority of the Member State in which the user or patient is established. -
Page 14: Glossary Of Symbols
An item with demonstrated safety in the MR environment within defined conditions. MR Conditional An item which poses unacceptable risks to the patient, medical staff or other persons within the MR environment. MR Unsafe 02082021V11IFU122500 MacroMedics ®... - Page 15 Manual BreastBoards & ThoraxSupports Instructions for use [ This page is intentionally left blank ] 02082021V11IFU122500 MacroMedics ®...
