- Page 1 MANUAL 123110 Instructions for use English Instructions MacroMedics EAMIS Lite ® (Extra Accurate Modular Immobilization System) MacroMedics BV Oostbaan 670 2841ML Moordrecht The Netherlands +31(0)182 389 777 info@macromedics.com www.macromedics.com...
- Page 2 Manual EAMIS Lite Instructions for use [ This page is intentionally left blank ] 26042021V6IFU123110 MacroMedics ®...
-
Page 3: Table Of Contents
EAMIS Lite Instructions for use Table of Contents 1. Warnings 2. MRI Safety Information 3. Intended Use 4. Installation Instructions of the EAMIS Lite 5. Cleaning, Storage and Disposal 6. Warranty 7. Notices 8. Glossary of Symbols 26042021V6IFU123110 MacroMedics ®... -
Page 4: Warnings
SBRT Secure Arch, size XS MR CONDITIONAL The following devices are MR conditional: • All Vacuum Cushions distributed by MacroMedics are MR Conditional. A patient with this device can be safely scanned in an MR system, meeting the following conditions: • A Static Magnetic field of 1.5 Tesla and 3 Tesla, with •... -
Page 5: Intended Use
Make sure that no movement is possible between the EAMIS and the CouchTop. III. PLACE THE VACUUM CUSHION Place a Vacuum Cushion onto the EAMIS Lite before positioning the patient. For the moulding of a Vacuum Cushion, refer to IFU155100 - Vacuum Cushions. POSITION THE PATIENT Position the patient carefully on the Vacuum Cushion. - Page 6 Select the appropriate size of SBRT Secure Arch. XS, S, M, L. Place the brackets carefully over the patient onto the rails of the EAMIS Lite. Be sure to place the SBRT Secure Arch in the right direction: see engravings on the SBRT Secure Arch for cranial/ caudal direction.
- Page 7 Manual EAMIS Lite Instructions for use VII. ADJUSTING THE HEIGHT OF THE SBRT SECURE ARCH Lower the SBRT Secure Arch as appropriate and hand-tighten it in the desired position by turning the knobs on the sides of the arch. Do not apply too much force as this may cause damage.
- Page 8 Manual EAMIS Lite Instructions for use ATTACHING THE ABDOMINAL VACUUM CUSHION To attach an Abdominal Vacuum Cushion to the SBRT Secure Arch, slot the white pins of the cushion into the holes at the top of the SBRT Secure Arch and slide the white sliding mechanism into the locked position.
-
Page 9: Cleaning, Storage And Disposal
Defects, malfunctions or failures caused by nature, misuse, abuse and unauthorised alteration or repair are not warranted. This warranty is limited to the repair and/or replacement at the sole discretion of MacroMedics. 7. Notices Any serious incident that has occurred in relation to the device should be reported to the manufacturer and the competent authority of the Member State in which the user or patient is established. -
Page 10: Glossary Of Symbols
Manual EAMIS Lite Instructions for use 8. Glossary of Symbols Symbol Symbol Name Description of Symbol EC declaration of conformity by manufacturer. European Conformity Indicates the medical device manufacturer. Manufacturer Indicates the manufacturer’s catalogue number so that the Catalogue Number medical device can be identified. - Page 11 Manual EAMIS Lite Instructions for use [ This page is intentionally left blank ] 26042021V6IFU123110 MacroMedics ®...
- Page 12 MacroMedics BV Oostbaan 670 2841ML Moordrecht The Netherlands +31(0)182 389 777 info@macromedics.com www.macromedics.com (Visit www.macromedics.com for a digital copy of this manual)
