- Page 1 MANUAL 123100 Instructions for use English Instructions MacroMedics ® SBRT Systems MacroMedics BV Oostbaan 670 2841ML Moordrecht The Netherlands +31(0)182 389 777 info@macromedics.com www.macromedics.com...
-
Page 2: Table Of Contents
Manual SBRT Systems Instructions for use Table of Contents 1. Warnings 2. MRI Safety Information 3. Intended Use 4. Installation Instructions - All baseplates, except HXP 5. Installation of Accessories 6. Installation Instructions - HXP Baseplates 7. Cleaning, Storage and Disposal 8. -
Page 3: Warnings
Manual SBRT Systems Instructions for use 1. Warnings • Inspect the device thoroughly before use. Do not use the device if damaged or if missing parts. • Check individual components on MR-safety when used together in a patient positioning system. -
Page 4: Intended Use
PelvMidBlock UTB Type-O • 123400 SBRT Secure Arch, size L • 125230 MultiBoard™ Mouldroom • 123460 SBRT Secure Arch, size L HXP • 125260 MultiBoard™ base-O, GF • 123500 SBRT Secure Arch, size M • 126260 Handgrips for DSCP™ set/2 •... -
Page 5: Installation Instructions - All Baseplates, Except Hxp
For use in MR, use a glass fi ber, MR safe 3-Pin CouchStrip. PLACE THE SBRT BASEPLATE Align the SBRT baseplate with the Couchstrips and slot it into place. Make sure that no movement is possible between the baseplate and the couch. -
Page 6: Installation Of Accessories
PLACING THE RESPIRATORY SUPPRESSION PLATE Slot the white pins of the Respiratory Suppression Plate into the holes at the top of the SBRT Secure Arch and slide the white sliding mechanism into the locked position. In the locked position, the arrows on the Arch and on the sliding mechanism of the Arch will be in-line with each other. - Page 7 PLACING THE ABDOMINAL VACUUM CUSHION Slot the white pins of the cushion into the holes at the top of the SBRT Secure Arch and slide the white sliding mechanism into the locked position. In the locked position, the arrows on the Arch and on the sliding mechanism of the Arch will be in-line with each other.
-
Page 8: Installation Instructions - Hxp Baseplates
Manual SBRT Systems Instructions for use Lower the Secure Arch by turning the knobs on the side of the Arch until the Vacuum Cushion is in tight contact with the patient. Make a vacuum mould. Lower the bridge again and fasten it in the desired position. - Page 9 PLACING THE ACCESSORIES Attach the required accessories following their instructions for use. Check the latest MacroMedics’ catalogue or contact your distributor for further information on available accessories. Note that the HXP baseplate secure arches differ from the secure arches for regular baseplates.
-
Page 10: Cleaning, Storage And Disposal
Defects, malfunctions or failures caused by nature, misuse, abuse and unauthorised alteration or repair are not warranted. This warranty is limited to the repair and/or replacement at the sole discretion of MacroMedics. 9. Notices Any serious incident that has occurred in relation to the device should be reported to the manufacturer and the competent authority of the Member State in which the user or patient is established. -
Page 11: Glossary Of Symbols
Manual SBRT Systems Instructions for use 10. Glossary of Symbols Symbol Symbol Name Description of Symbol EC declaration of conformity by manufacturer. European Conformity Indicates the medical device manufacturer. Manufacturer Indicates the manufacturer’s catalogue number so that the Catalogue Number medical device can be identifi... - Page 12 MacroMedics BV Oostbaan 670 2841ML Moordrecht The Netherlands +31(0)182 389 777 info@macromedics.com www.macromedics.com (Visit www.macromedics.com for a digital copy of this manual)
