Hoover's quick
& snappy start
up guide.
Let's get your cooktop
up and running!
Welcome to your new Hoover cooktop! We hope that this product brings you many years of enjoyment.
NOTE: This cooktop must be installed by a licensed plumber/gasfitter. You are not allowed to do this
yourself. Installation involves cutting out an appropriate opening in your benchtop, applying a seal to the
cooktop, fixing it in place and connecting it to your electricity and gas supply.
This cooktop is fitted out for use with Natural Gas (NG). If you want to use it with Universal Liquefied
Petroleum Gas (ULPG), the burners have to be converted. Your licensed gasfitter/plumber will be able to do
this. Please pass on the supplied instruction manual to your professional installer.
For detailed installation instructions, please consult the supplied instruction manual, which also has
comprehensive usage instructions and important safety advice.
Controls
• The control panel at the front of the cooktop has five control knobs, one for
each burner; the small diagram to the left of each knob illustrates which
burner it controls.
• The black circle above each knob indicates that the gas is OFF.
• The large circle at the left of each control knob indicates the HIGH
(maximum) setting.
• The small circle at the bottom right of each control knob indicates the LOW
(minimum) setting.
Cooktop
• The cooktop has five burners: one wok (W), one
auxiliary (A), one rapid (R) and two semirapid (SR),
each fitted with a flame failure safety device which
stops the flow of gas if the flame goes out. Three
cast iron trivets fit over the burners.
• To light a burner, press down the knob, turn it
anticlockwise to the maximum position and keep it
depressed for around 15 seconds to ensure it stays
lit. Turn the knob to a position between HIGH and
LOW, not between OFF and HIGH.
• After use, always turn the control knob back to the
OFF position.
• Press and hold a button, as instructed on the panel,
to activate the child lock, or to mute the alert sound.
90 cm Glass Gas
Cooktop
90 cm Glass Gas
Cooktop
Model #:
Version #:
After Sales Support
1
2
SR
W
A
HV-C90CG
V1.0
1300 886 649
R
SR
HV-C90CG
