Summary of Contents for Hoover HV-C60CC
- Page 1 60cm Ceramic Cooktop 版本 日期 物料编码 客户型号 型号 客户 制作 美的海外营销 尺寸 颜色 Model Number: HV-C60CC 12566100001184 陶瓷板丝印图纸 590x520x4 灰 HF605 苏泳梅 INSTRUCTION MANUAL AFTER SALES SUPPORT (AU) 1300 886 649 (NZ) 0800 836 761 E209...
-
Page 2: Table Of Contents
Contents 03 General Safety Instructions 06 Product Overview 08 Installation 17 Getting Started 19 Instructions 28 FAQs & Troubleshooting Guide 29 Other Useful Information After Sales Support (AU) 1300 886 649 (NZ) 0800 836 761 | tempo.org/support... -
Page 3: General Safety Instructions
General Safety Instructions IMPORTANT SAFETY INSTRUCTIONS: READ CAREFULLY AND KEEP FOR FUTURE REFERENCE! Read this manual thoroughly before first use, even if you are familiar with this type of product. The safety precautions enclosed herein reduce the risk of fire, electric shock and injury when correctly adhered to. - Page 4 General Safety Instructions (Cont.) • No timer: The appliance is not intended to be operated by means of an external timer or separate remote control system. • RCD: Unless your home is already fitted with a residual current device (safety switch), we recommend installing an RCD with a rated residual operating current not exceeding 30 mA to provide additional safety protection when using electrical appliances.
- Page 5 General Safety Instructions (Cont.) • Disconnect the appliance from the electrical outlet before carrying out any maintenance on it. • Winding the cord: If winding the power cord, avoid tight bends as this could damage the cord. • Damaged supply cord: The power supply cord must be checked regularly and if it is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified person in order to avoid a hazard.
-
Page 6: Product Overview
Product Overview Ceramic cooktop Control panel 版本 日期 物料编码 客户型号 型号 客户 制作 美的海外营销 尺寸 颜色 12566100001184 陶瓷板丝印图纸 590x520x4 灰 HF605 苏泳梅 NOTE: Please see opposite for part descriptions. After Sales Support (AU) 1300 886 649 (NZ) 0800 836 761 | tempo.org/support... - Page 7 Product Overview (Cont.) Scope of delivery (A) Electric ceramic cooktop Max. 1200 W cooking zone (165 mm ø) Max. 1800 W cooking zone (200 mm ø) Ceramic glass plate ON/OFF control Control panel (B) Control panel Timer controls Child lock control Cooking zone controls (C) Installation hardware Cooktop mounting brackets and screws (x4)
-
Page 8: Installation
Installation Unpacking the appliance • This product has been packaged to protect it against transportation damage. Unpack the appliance and remove all packaging materials from around all parts of the appliance. • WARNING: Cut Hazard! Take care, the panel edges are sharp. Failure to use caution when unpacking and installing the appliance could result in injury or cuts. - Page 9 Installation (Cont.) Important installation advice Kitchen and benchtop requirements • Kitchen area: Before installation, make sure the kitchen area is dry and there is sufficient ventilation and easy access to all control elements. • Benchtop: The benchtop surface must be level, and no structural members must interfere with space requirements.
- Page 10 Installation (Cont.) Important clearances • Walls or vertical structures must be at least 200 mm away from the cooktop. • Overhanging surfaces: There must be no overhanging surfaces, and no rangehood or exhaust system within 760 mm above the cooktop. •...
- Page 11 Installation (Cont.) Benchtop preparation The cooktop can be fitted to any benchtop with a minimum thickness of 30 mm. For the purpose of installation and use, make sure to maintain a minimum space of 50 mm around the opening. To install the cooktop on your benchtop, make an opening with the dimensions given in Fig.
- Page 12 Installation (Cont.) Ventilation and space requirements • Make sure to observe the clearance requirements as illustrated in Fig. 3 and Fig. 4. • The minimum distance between the cooktop and the cupboard above the hotplate must be 760 mm. Fig. 3 Fig.
- Page 13 Installation (Cont.) Inserting and fixing the cooktop • Carefully lower the cooktop into the aperture hole that you have cut out. • Using the screws provided, affix the 4 mounting brackets to the underside of the cooktop, as illustrated (Fig. 5). Fig.
- Page 14 Installation (Cont.) Electrical connection WARNING: Electric Shock Hazard! The connection to the electricity supply, and any eventual alterations to the domestic wiring system, must only be made by a licensed electrician and following all applicable regulations in force. Connection to an appropriately earthed wiring system is essential and mandatory.
- Page 15 Installation (Cont.) Connecting the cooktop to the mains power supply The power supply should be connected in compliance with any relevant standards, or a single-pole circuit breaker, according to the connection method shown in Fig. 7. Fig. 7 After Sales Support (AU) 1300 886 649 (NZ) 0800 836 761 | tempo.org/support...
- Page 16 Installation (Cont.) Wiring diagram (Fig. 8) 1200W 6,30,54 1800W Control line 15,39,63 Earth 1800W 15,39,63 2～3 1200W 6,30,54 CP1_2 CP3_4 After Sales Support (AU) 1300 886 649 (NZ) 0800 836 761 | tempo.org/support...
-
Page 17: Getting Started
Getting Started Before first use When your new ceramic cooktop has been professionally installed, follow a few simple steps to prepare it for your first use. • Most importantly, read this manual thoroughly to familiarise yourself with the appliance. Pay particular attention to the safety instructions on pages 3-5. - Page 18 Getting Started (Cont.) Choosing the right cookware Keep the following points in mind when selecting pots and pans for use on the ceramic cooktop. They will ensure efficient heat transfer, save you energy and cooking time, and help you keep the cooktop in optimum condition. It is particularly important that the bases of the pots and pans you are using are in good condition.
-
Page 19: Instructions
Instructions Using the ceramic cooktop Once the cooktop has been connected to the power supply, the buzzer will emit a beep sound and all indicators light up briefly and then go out. This indicates that the ceramic cooktop has entered the state of standby mode. To start cooking 1. - Page 20 Instructions (Cont.) When you have finished cooking 1. Turn the cooking zone off by Fig. 16 touching the control until [ 0 ] is shown, or by touching the controls at the same time (Fig. 16). 2. Turn the whole cooktop off by touching the ON/OFF control Fig.
- Page 21 Instructions (Cont.) Safety features Child lock You can lock the controls to prevent unintended use, for example, children accidentally turning the cooking zones on. When the controls are locked, all the controls are disabled, except the ON/OFF control. • To lock the controls, touch the child lock control.
- Page 22 Instructions (Cont.) Using the timer Your cooktop timer can be set (for up to 99 minutes) in two different ways: • You can use it as a minute minder. In this case, the timer will NOT turn any cooking zone off when the set time is up. •...
- Page 23 Instructions (Cont.) Using the timer as a minute minder NOTE: You can use the timer as a minute minder function, provided that: (a) the cooktop is turned on (b) you have at least one cooking zone in use. 1. Adjust the timer setting by touching the Fig.
- Page 24 Instructions (Cont.) Setting the timer to turn one cooking zone off Fig. 24 1. Touch the control of the corresponding cooking zone you want to set the timer for (Fig. 24). 2. Set the time by touching the timer controls (Fig. 25). * Touch the timer controls once Fig.
- Page 25 Instructions (Cont.) Setting the timer to turn more than one cooking zone off To set timers for more than one cooking zone, proceed as follows: 1. Set the timer for each cooking zone, as described on page 24. 2. If you have set a timer for multiple cooking zones, the timer indicator shows the shortest time set.
- Page 26 Instructions (Cont.) Cooking guidelines IMPORTANT! Take utmost care when frying as oil and fat heat up very quickly. At extremely high temperatures oil and fat will ignite spontaneously and this presents a serious fire risk. General cooking tips • Always place a (filled) pot on the cooking zone before switching it on. Do not heat up a zone without pot, or with an empty pot.
- Page 27 Instructions (Cont.) Stir-frying • Choose a ceramic compatible, flat-based wok or a large fry pan. • Have all the ingredients and equipment ready. Stir-frying should be quick. If cooking large quantities, cook the food in several smaller batches. • Preheat the pan briefly and add two tablespoons of oil. •...
-
Page 28: Faqs & Troubleshooting Guide
FAQs & Troubleshooting Guide If you experience problems with your ceramic cooktop, or it appears not to be operating correctly, check in Table 3 below for solutions to common problems. If none of the solutions offered help you solve your problem, please contact our after sales support centre for advice;... -
Page 29: Other Useful Information
Other Useful Information Cleaning and maintenance GENERAL CAUTIONS • Before cleaning the cooktop or carrying out any maintenance, always switch off the appliance. • Always allow the cooktop surface to cool before cleaning the cooktop. • You may find it easier to clean some deposits while the cooktop surface is still warm. - Page 30 Other Useful Information (Cont.) Boil-overs, melts, and hot sugary spills on the glass Remove these immediately with a fish slice, palette knife or razor blade scraper suitable for ceramic glass cooktops, but beware of hot cooking zone surfaces. 1. Use the ON/OFF control to switch off the cooktop.
- Page 31 To find out more, or to purchase a part, contact the centre at tempo.org/support or on 1300 886 649. Technical specifications Model Number HV-C60CC Cooking Zones 2x 1800 W (200 mm diameter) 2x 1200 W (165 mm diameter)
- Page 32 Other Useful Information (Cont.) Responsible disposal Packaging materials are recyclable. Please dispose of them responsibly for recycling. At the end of its working life, do not throw this appliance out with your household waste. Electrical and electronic products contain substances that can have a detrimental effect on the environment and human health if disposed of inappropriately.
- Page 33 Other Useful Information (Cont.) Licensed installer details Please ask your licensed installer/electrician to fill in the details below (or in the INSTALLATION manual) so you have them on record should you need to contact the installer in the future. Proof of professional installation is also required for warranty claims. Please fill in the details below: Name of licensed installer: ............
- Page 34 This page has been left blank intentionally After Sales Support (AU) 1300 886 649 (NZ) 0800 836 761 | tempo.org/support...
- Page 35 This page has been left blank intentionally After Sales Support (AU) 1300 886 649 (NZ) 0800 836 761 | tempo.org/support...
- Page 36 Warranty returns Should you for any reason need to return this product for a warranty claim, make sure to include all accessories with the product. Product does not work? If you encounter problems with this product, or if it fails to perform to your expectations, make sure to contact our After Sales Support Centre on (AU) 1300 886 649 or (NZ) 0800 836 761 for advice.
