Specifications
Outputs
Optimization
Controls and Indicators
Connectors
General
Lexicon Inc.
3 Oak Park
Bedford MA 01730-1441
Telephone 617-280-0300
Fax 617-280-0490
Lexicon Part # 070-11659 Rev 1
Inputs
2: 1AC-3/RF via COAX; 2 Digital (1 COAX; 1 Optical)
One (1) Digital via COAX
3-position toggle switch, decoder pulse settings
LEDs indicate operational status
Toggle switches for: LD Optimization: High, Low, Normal; Input Select: Optical, COAX
Inputs: 4: 2 RCA (COAX); 1 TOSLINK (Optical); 1 5-pin DIN (PWR CTL)
Outputs: 2: 1 RCA (COAX); 1 5-pin DIN (PWR CTL Thru)
Power connector: 2.5mm, 9VAC, 1A
Dimensions: 17.0"X x 1.75"H x 4"D
Weight: 2.4 lbs net; 4.4 lbs shipping
Power Requirements: 120VAC, 60Hz or 230VAC, 50Hz. Use Lexicon MSA AC Power Adapter.
Rack mount adapters are available through your Lexicon dealer.
All specifications subject to change without notice.
Printed in U.S.A.
