VOH SA GU-04-06-01 Version 1.1 VOHIV 4.0 – User Guide 09.2022 Page 1 / 20 Table of content General ................................. 2 Warranty ..............................2 Security informations ..........................2 Transport ..............................3 Storage ..............................3 Specifications .............................. 3 First use ............................... 4 Get started .............................. -
Page 3: General
1.2 Security informations Warning ▪ Do not use the VOH IV if it is damaged. Before using the VOH IV, inspect its housing and electrical connections. ▪ The VOH IV should be used according to the manufacturer's instructions. ▪... -
Page 4: Transport
1.4 Storage VOH IV should be stored in a dry and dust-free place. The storage temperature should be between 10°C and 40°C. It is highly recommended to cover the device to protect it from dust and moisture. -
Page 5: First Use
Plug-in location (0), Power on the device by switching the power switch (1) Adjust the sharpness of the binocular LEICA by using the knob 12. The zoom can be adjusted by using the knob 13. (adjustment of the LED lightning, see chapter 6.3) -
Page 6: Standard Display
09.2022 Page 5 / 20 3.2 Standard Display Figure 2: VOH IV, Home screen (WM1301) Navigation (upper left corner) To navigate through the different pages of the device, use the icons in the upper left section. The red icon indicates the current page, while the white icons allow access to other pages. -
Page 7: Working Progress
Before any intervention, you must switch off the device by its main switch (1), remove the power supply plug (15) and wait 30 minutes so the unit cools down. Display VOH IV Comments Device The warm-up time is approx. - Page 8 VOH SA GU-04-06-01 Version 1.1 VOHIV 4.0 – User Guide 09.2022 Page 7 / 20 Set the digital number on the display to 0, by using the adjustment wheel (10) Lock the pallet fork by gently moving the rolling clamp (3) against the front until it stops.
- Page 9 Page 8 / 20 Gently pull the pallet fork away from the touching elements. Note: If, during handling, you drop your pallet fork inside the VOH IV, you can retrieve it by removing the recovery tray (16). © Copyright VOH SA...
-
Page 10: Settings When Changing Pallet Fork Type
4 Settings when changing pallet fork type Below are the settings to be made the first time or when changing the type of the pallet fork. 4.1 Adjusting the stop Display VOH IV Comments Device This stop must be adjusted to a gap of ~ 0.1 mm between the body of the pallet fork and the end of the clamp. -
Page 11: Adjustment Of The Pallet Fork Locking Force
GU-04-06-01 Version 1.1 VOHIV 4.0 – User Guide 09.2022 Page 10 / 20 4.3 Adjustment of the pallet fork locking force Display VOH IV Comments Device The locking force of the pallet fork, can be adjusted by screwing (... -
Page 12: Details Of The User Interface
VOHIV 4.0 – User Guide 09.2022 Page 11 / 20 5 Details of the user interface 5.1 Selection of the user type Display VOH IV Comments Device From the home screen (WM1301), click on the bottom navigation icon. If the current user is « Operator », the administrator password will be requested. -
Page 13: Device Settings
As ADM : changing password for the « Administrator » 5.3 Device settings The device settings are only avaliable on « Administrator » mode. Display VOH IV Comments Device From the page « Settings » (WM1302), click on the button « Device settings »... -
Page 14: The Preset Function
With Preset function enabled, an operator can select different types of pallet forks but is not allowed to change temperature or the position for the 0. Figure 3: VOH IV, OPE home screen with preset function enabled (WM1301) 5.4.1.1 Select a pallet fork... -
Page 15: Administrator Home Screen With Preset Function
Version 1.1 VOHIV 4.0 – User Guide 09.2022 Page 14 / 20 Administrator home screen with Preset function Figure 4: VOH IV, ADM home screen with preset function enabled (WM1301) 5.4.2.1 Add a pallet fork Display VOH IV Comments Device On «... - Page 16 5°C.(41°F) Once the pallet fork is edited, just save it with the « Check » button. 5.4.2.2 Edit or delete a pallet fork Display VOH IV Comments Device On « home screen » (WM1302) on ADM mode, click on the bottom center button to show the list of pallet forks.
-
Page 17: Link References To Different Types Of Pallet Forks (Preset Mod Activated)
5.5 Link references to different types of pallet forks (Preset mod activated) The VOH IV Device allows references to be linked to pallet fork types. These references are scanned via the Blutetooth scanner, and the corresponding pallet fork is automatically loaded. -
Page 18: Link A Reference
Version 1.1 VOHIV 4.0 – User Guide 09.2022 Page 17 / 20 Link a reference Display VOH IV Comments Device To Link a reference to one type of pallet fork, begin to edit the selected pallet fork. On the « Home screen » (WM1302) on... -
Page 19: Safety Measures
Version 1.1 VOHIV 4.0 – User Guide 09.2022 Page 18 / 20 6 Safety measures Display VOH IV Comments Device Adjust the carriage to approx. +500 µm by using the micrometric screw (10). Close the clamp for the pallet (18) by using the eccentric lever (5). -
Page 20: Disclaimer Of Liability/Warranty
