Nautilus NS-600 Assembly Instructions Manual page 2

Gym Components
1 Main Base
2 Rear Frame
3 Top Frame
4 Front Upright
5 Leg Extension Frame
6 Pulley Mount
7 Calf Raise / Low Pulley Frame
8 Top Stack Support Frame
9 Cable Housing
10 2 inch Backing Plate
11 3 inch Backing Plate
12 Press Arm Support Assembly
13 Press Arm
14 Right Press Arm Handle
15 Left Press Arm Handle
16 Pec Fly Mount
17 Pec Fly Cam
18 Right Pec Fly Arm
19 Left Pec Fly Arm
20 Pec Fly Handle
21 Pec Fly Pulley Bracket
22 Seat Adjuster
23 Seat Cross Tube
24 Back Pad Tube
25 Back Pad Adjuster
26 Back Pad Adjustment Plate
27 Seat Pad
28 Back Pad
29 Pulley Bracket
30 Pec Double Floating Pulley Bracket
31 Double Floating Pulley Bracket
32 Guide Rod Holder
33 Low Pulley Cover
34 T Handle Pop Pin
35 Locking Roller Pad
36 Foam Roller Pad 8"L
37 Locking Roller End Cap
38 Roller End Cap
39 Plastic Washer
40 Locking Roller Bar
41 Roller Bar
42 Plastic Cap
43 3 1/2" Pulley
44 4 1/2" Pulley
45 Press Arm Support Shaft
46 Press Arm Pivot Shaft
47 Snap Cap Large
48 Top Weight Assembly
49 Weight Plate
50 Weight Stack Bottom Plate
51 Weight Stack Cushion
52 Guide Rod
TM
Part #
1 14786
1 14785
1 14124
1 14787
1 14434
1 14788
1 14127
1 14125
1 14137
3 14105
1 14007
1 14132
1 14131
1 14133
1 14134
1 14135
2 14473
1 14148
1 14149
2 14151
1 14438
1 14128
1 14101
1 14465
1 14456
1 14469
1 14190
1 14189
1 14136
1 14138
2 14138
1 14174
2 14437
1 14211
2 14493
2 14270
2 14486
2 14165
2 92058
1 14460
1 14100
4 14158
2 14173
9 14537
1 14111
1 14110
2 14182
1 14679
19 14342
1 14106
2 14176
2 14102
2
Gym Components
CABLE
53 Cable #1 - Pulldown Cable (226")
54 Cable #2 - Mid Pulley Cable (96.75")
55 Cable #3 - Low Row Cable (137.75")
56 Cable #4 - Pec Fly Cable (122.5")
HARDWARE
57 Hex Bolt - 1/2" x 3 1/4"L
58 Hex Bolt - 3/8" x 4 1/2"L
59 Hex Bolt - 3/8" x 4 1/4"L
60 Hex Bolt - 3/8" x 4"L
61 Hex Bolt - 3/8" x 3 1/4"L
62 Hex Bolt - 3/8" x 3"L
63 Hex Bolt - 3/8" x 2 3/4"L
64 Hex Bolt 3/8" x 2 1/4"L
65 Hex Bolt 3/8" x 2"L
66 Hex Bolt - 3/8" x 1 3/4"L
67 Hex Bolt - 3/8" x 1 1/2"L Threadlock
68 Cap Head Screw 1/4 x 1"L Threadlock
69 Cap Head Screw 1/4" x 1/2"L Threadlock
70 Button Head Screw 1 3/4"L
71 Button Head Screw 1"L Threadlock
72 1 3/8" x 1/2" Flat Washer
73 1" x 1/2" Flat Washer
74 3/8" Flat Washer
75 Shim Washer
76 1/2" Lock Nut
77 3/8" Lock Nut
78 Pulley Spacer 1"L
79 Step Spacer 5/8"H
80 Step Spacer 1"H
81 Step Spacer 21/32"H
82 Set Screw 5/16" x 1/4"L
ACCESSORIES AND TOOLS
83 Rower Bar
84 AB Strap
85 Felt Back Ankle Strap
86 Dual Ring Handle Strap
87 Chain
88 Lat Bar
89 Cable Clip
90 Weight Selector Pin
91 M4 Allen Wrench
92 M5 Allen Wrench
93 M6 Allen Wrench
94 M8 Allen Wrench
95 Touch Up Paint White
96 Touch Up Paint Gray
97 NS 600 Documentation
98 Decal Kit
Part #
1 14791
1 14792
1 14793
1 14794
1 14243
1 92170
4 14246
1 14247
8 14267
16 14245
4 14241
3 14265
5 14242
3 14239
2 14249
2 14258
2 14259
2 14256
4 14251
4 14272
4 14273
87 14233
4 14274
7 14232
42 14234
1 14196
4 14195
2 14795
2 14796
6 14277
1 14113
1 14215
1 14217
1 14384
1 92053
1 14142
4 92054
1 14210
1 14680
1 14532
1 14533
1 14534
1 14536
1 14535
1 14797
1 14789
NS-600
