- Page 1 Si011088 REMOVAL PROCEDURE S E R V I C E M A N U A L 6.0 kW Class Outdoor Unit Non-inverter Pair Type...
- Page 2 Service Manual Removal Procedure Outdoor Unit Heat Pump RYN60HV1A...
-
Page 3: Table Of Contents
Si011088 Table of Contents 1. Removal of Outer Panels ................2 2. Removal of Outdoor Fan / Fan Motor .............5 3. Removal of Thermistor ASSY ..............9 4. Removal of Electrical Components ............12 5. Removal of Electronic Expansion Valve ..........16 6. Removal of Sound Blankets..............20 7. -
Page 4: Removal Of Outer Panels
Removal of Outer Panels Si011088 1. Removal of Outer Panels Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points 1. Remove the top panel. Top panel Remove the 8 screws of the top panel. - Page 5 Si011088 Removal of Outer Panels Step Procedure Points Unfasten the hooks with a flat screwdriver and remove the suction Hook grille. (R5427) 2. Remove the front panel (2). Remove the screw and remove the front panel (2). Front panel (R12807) When reassembling, fit the 5 hooks.
- Page 6 Removal of Outer Panels Si011088 Step Procedure Points 4. Remove the front panel (1). Remove the 6 screws and remove the front Front panel panel (1). (R13429) (R13317) (R13430) Removal Procedure...
-
Page 7: Removal Of Outdoor Fan / Fan Motor
Si011088 Removal of Outdoor Fan / Fan Motor 2. Removal of Outdoor Fan / Fan Motor Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points 1. Remove the outdoor fan. Preparation Outdoor fan Remove the front panel... - Page 8 Removal of Outdoor Fan / Fan Motor Si011088 Step Procedure Points Cut the 2 clamps. (R13439) Unfasten the hooks. (R13440) Removal Procedure...
- Page 9 Si011088 Removal of Outdoor Fan / Fan Motor Step Procedure Points Unfasten the hook with a flat screwdriver. (R13441) Release the fan motor Put the fan motor lead wire lead wire. through the back of the fan motor when reassembling so as not to be entangled with the outdoor fan.
- Page 10 Removal of Outdoor Fan / Fan Motor Si011088 Step Procedure Points Remove the fan motor fixing plate. Fan motor fixing plate (R13444) Remove the 4 screws. (R13445) Remove the fan motor. Fan motor (R13438) Removal Procedure...
-
Page 11: Removal Of Thermistor Assy
Si011088 Removal of Thermistor ASSY 3. Removal of Thermistor ASSY Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Cut the clamp. (R13454) Release the outdoor temperature thermistor ASSY. - Page 12 Removal of Thermistor ASSY Si011088 Step Procedure Points Pull out the outdoor Be careful not to lose the clip heat exchanger for the thermistor. thermistor. Clip (R3264) Outdoor heat exchanger thermistor (R13457) Cut the clamp. (R13458) Release the discharge Be careful not to lose the clip pipe thermistor.
- Page 13 Si011088 Removal of Thermistor ASSY Step Procedure Points Remove the thermistor ASSY. (R13459) Removal Procedure...
-
Page 14: Removal Of Electrical Components
Removal of Electrical Components Si011088 4. Removal of Electrical Components Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points 1. Remove the compressor motor capacitor. Compressor motor capacitor (R13461) Pull out all the 3... - Page 15 Si011088 Removal of Electrical Components Step Procedure Points Remove the compressor motor capacitor. Compressor motor capacitor (R13434) 2. Remove the magnetic contactor. Pull out all the 6 terminals. (R13448) Remove the 2 screws. Remove the magnetic contactor. Magnetic contactor (R13449) Removal Procedure...
- Page 16 Removal of Electrical Components Si011088 Step Procedure Points 3. Remove the fan motor capacitor. Pull out the 2 terminals. (R13446) Remove the screw. Remove the fan motor capacitor. Fan motor capacitor (R13447) 4. Remove the PCB. Disconnect the connectors [S5], [S7], [S80].
- Page 17 Si011088 Removal of Electrical Components Step Procedure Points Disconnect the connectors [S8], [S20], [S90]. [S90] [S20] (R13464) [S8] Pinch the PCB spacers PCB spacer and pull out the PCB. Remove the PCB. (R13465) [S5] : AC fan motor [S90] [S7] : terminal board [S8] : compressor [S20]: electronic expansion valve [S80]: four way valve coil...
-
Page 18: Removal Of Electronic Expansion Valve
Removal of Electronic Expansion Valve Si011088 5. Removal of Electronic Expansion Valve Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Remove the 6 screws Preparation of the side panel. - Page 19 Si011088 Removal of Electronic Expansion Valve Step Procedure Points Disconnect the relay connector for the fan motor. (R13469) Cut the clamp. (R13470) Pull out the 2 upper terminals (red and blue) of the magnetic contactor. [Red] [Blue] (R13471) Removal Procedure...
- Page 20 Removal of Electronic Expansion Valve Si011088 Step Procedure Points Cut the clamp. (R13472) Pull out the 2 rear [Red] terminals (yellow and [Yellow] red) of the compressor motor capacitor. (R13450) Cut the clamp. (R13451) Removal Procedure...
- Page 21 Si011088 Removal of Electronic Expansion Valve Step Procedure Points 10 Release the harnesses from the clamp (at the back of the electrical components ASSY). (R13453) 11 Unfasten the 2 hooks. Lift and remove the electrical components ASSY. (R13468) 12 Remove the electronic expansion valve.
-
Page 22: Removal Of Sound Blankets
Removal of Sound Blankets Si011088 6. Removal of Sound Blankets Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Remove the sound Preparation Sound blanket blanket (top). Remove the electrical box (Top) according to the "Removal of... -
Page 23: Removal Of Four Way Valve
Si011088 Removal of Four Way Valve 7. Removal of Four Way Valve Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points Step Remove the screw and Four way value coil remove the four way Warning valve coil. - Page 24 Removal of Four Way Valve Si011088 Step Procedure Points Heat up every brazed part in turn and disconnect. (R13479) Removal Procedure...
-
Page 25: Removal Of Compressor
Si011088 Removal of Compressor 8. Removal of Compressor Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Remove the nut and Terminal cover remove the terminal cover. - Page 26 Removal of Compressor Si011088 Step Procedure Points Remove the 4 nuts of the compressor. Warning Be careful not to get yourself burnt with the pipes and other parts that are heated by the gas brazing machine. Warning Before working, make If the refrigerant gas leaks sure that the refrigerant is during work, ventilate the...
- Page 27 Revision History Month / Year Version Revised contents 01 / 2013 Si011088 First edition...
- Page 28 Improper installation can result in water or refrigerant leakage, electrical shock, fire or explosion. Use only those parts and accessories supplied or specified by Daikin. Ask a qualified installer or contractor to install those parts and accessories. Use of unauthorised parts and accessories or improper installation of parts and accessories can result in water or refrigerant leakage, electrical shock, fire or explosion.
