1 INTRODUCTION

1.1 ALLinBOX 1612 V2

ALLinBOX 1612 v2 is a versatile KNX actuator featuring a wide variety of functions:
16 relay outputs, configurable as:
➢ Up to 8 independent shutter channels (with or without slats),
➢ Up to 16 individual ON/OFF outputs,
➢ Up to 2 1 fan coil modules,
➢ A combination of the above.
12 multi-purpose inputs, configurable as:
➢ Temperature probes (possibility to parameterise a personalised probe),
➢ Binary inputs (i.e., pushbuttons, switches, sensors),
➢ Motion detectors.
20 customisable, multi-operation logic functions.
Up to 4 standard thermostats and 4 Hospitality thermostats.
2 master light control instances for an easy, out-of-the-box control of a set
of luminaires (or functionally equivalent devices) one of which acts as a
general lamp and the others as secondary lamps.
Manual operation / supervision of the 16 relay outputs through infrared.
Scene-triggered action control, with an optional delay in the execution.
Relay switches counter.
Heartbeat or periodical "still-alive" notification.
