1.5 HARD RESET TO FACTORY DEFAULTS

By pressing the "IP Factory Reset" button for three seconds:
The device will adopt an IP address via the DCHP server.
➢ If the DHCP client does not obtain a valid IP address (after several
attempts), then the device will be assigned an IP address via the AutoIP
(APIPA)
The factory reset indicator LED will light up in red.
If a second-long press is made on the "IP Factory Reset" button
The device will adopt a static IP address.
➢ If "Use a static IP address" has been chosen in the ETS configuration, the
device will have the configured IP.
The factory reset led will light up in green.
➢ If, on the other hand, in the ETS configuration "Obtain an IP address
automatically" has been chosen, the device will obtain an IP by means of
AutoIP (APIPA).
The factory reset indicator LED lights up yellow.
The factory IP setting and the colour of the factory reset LED will remain until the
device is restarted.
The following table summarizes the above:
Press
st
1 long press
(3s)
nd
2 long
press (3s)
1
Random static IP configuration in the range 169.254.1.0 - 169.254.254.255
http://www.zennio.com
1
protocol.
ETS Configuration
Obtain an IP automatically
Use a static IP address
Obtain an IP automatically
Use a static IP address
IP Configuration
IP obtained by DHCP.
(If a valid IP is not obtained 
IP by APIPA)
IP obtained by APIPA
Static IP of ETS configuration
Technical Support: http://support.zennio.com
ALLinBOX 1612 v2
LED
Red
Yellow
Green
10
