If the compact remote module takes over control of the
system, or powers up with the compact remote module in
charge, the power button LEDs, speed indicator, connectivity
indicator and the selected profile on the compact remote
module on the compact remote module switch on
immediately. If the primary remote module has control
of the system, all LEDs switch off on the compact remote

module.

5.6.3 Restricted User Indication

The secondary remote can not become the remote-in-charge,
if a restriction has been set. When a restricted user requests
control, the request is denied. The status LED lights up
green, then dims and finally switches off again.
For restricting a remote, contact your Invacare
provider.

5.6.4 Sleep Indication

When transitioning into sleep mode, all lit LEDs start
dimming for a period of two seconds until LEDs are
completely switched off. All indicators remain switched off
when the system is in sleep mode.
Deactivate sleep mode during transition period by
moving joystick or pressing power button.
For setting sleep mode, contact your Invacare
provider.
1195718-A

5.6.5 OON Indication

OON ("Out Of Neutral") is a safety feature that prevents
accidental driving or seating movements, when:
• the system is powering up,
• after a function change or
• when the system comes out of an inhibit or drive
lock-out.
Drive OON Warning
The joystick must be in the center position:
• when the system is powering up,
• on a function change or
• when transitioning from a drive lock-out or inhibit state.
Otherwise a drive OON warning is displayed.
During a drive OON warning, the LEDs flash continually to
alert the user, and the mobility device does not drive. If
the joystick is returned to the center position, the warning
clears and the mobility device drives normally.
Seating OON Warning
Fig. 5-9
Fig. 5-10
