Invacare LINX ACU User Manual page 19

LiNX® Control System
The drive indicator C lights up in combination with or
without other indicators when:
• Mobility device is ready to drive. See 5.6.1
Attendant-in-Charge Indication (Attendant Control Unit),
page 26 and 5.6.2 User-in-Charge Indication (Compact
Remote Module), page 26.
• A new drive function has been selected.
• Mobility device can be driven at reduced speed only.
See 5.6.6 Drive Slow-Down Indication, page 28.
• Joystick is not in center position. See 5.6.5 OON
Indication, page 27.
• Mobility device can not be driven at all. See 5.6.8
Blocked Function Indication, page 28 and 5.6.7 Lock-Out
Indication, page 28.
Seating Indicator
The seating indicator B shows the selected seating function.
For changing the seating function, see 5.4 Mode Button,
page 24.
For a list of seating functions, see below.
18
Fig. 4-6
Icon Seating function
Tilt
Lifter
Right Leg
Recline
Left Leg or powered
center-mounted legrest
1195718-A
