LiNX® Control System
the mobility device must be remote-in-charge. If the remote
that you want to perform an emergency stop on is not
remote-in-charge, you must request control to be in-charge
of the mobility device first. See 5.1 Requesting Control of
the Mobility Device, page 22.
Press the button.
If the remote-in-charge has been restricted, the
mobility device does not perform an emergency stop.
Using Lock Function
The lock function prevents unintentional use of the system.
See 5.5 Lock Mode, page 25.
Disabling Connectivity System-Wide
This chapter applies only for compact remote
modules CREM and CREM-LF.
Connectivity gives access to more profiles. Connectivity can
be disabled.
Press and hold button for three seconds during powering up.
The connectivity indicator and status LED pulse slowly for
five seconds, then connectivity indicator LED switches off.
24
Interrupting or Waking Up from Sleep
Before the system goes to sleep there is a transition period
during which you can interrupt the system from going to
sleep.
Press the button.
Or:
Move the joystick.

5.4 Mode Button

Fig. 5-3 Mode Button on
Attendant Control Unit
The Mode button B is on the right-hand side of the remote
module and contains a status LED that lights up, flashes or
pulses depending on the status of the system:
• Lit together with all other LEDs on display — system
powering up or remote has become remote-in-charge.
See 5.6.1 Attendant-in-Charge Indication (Attendant
Control Unit), page 26 and 5.6.2 User-in-Charge
Indication (Compact Remote Module), page 26.
• Flashing 3x — remote locked. See 5.5 Lock Mode, page
25.
• Lit while all other indicators are switched off —
firmware upgrade mode.
Fig. 5-4 Mode Button on Compact
Remote
1195718-A
