Leica Geovid 56 Brochure

Identify the game confidently – with the Geovid class from Leica
Leica is the first optics specialist to succeed in combining uncompromising high-
performance optics and a laser rangefinder in a particularly compact binocular. This
innovative concept for modern hunting optics has now been implemented for the first
time in the form of a classic binocular for hunting from a stand – with a performance
that is unmatched ! With the LEICA GEOVID 8 x 56 BRF, Leica defines a new era of high-
performance optics for hunting and demonstrates what is technically feasible – for a
modern, sportsmanlike way of hunting.
Innovative and multifunctional
The first 8 x 56 with Leica high-performance optics and an integrated laser range-
finder – for identifying game with confidence while simultaneously determining
its exact distance.
Compact and lightweight
The LEICA GEOVID 8 x 56 BRF, weighing only 1,100 g (less than 39 oz) including
battery, and with a length of only 182 mm, is by far the lightest and most compact
8 x 56 binocular – as compared to conventional binoculars in this category without
rangefinders.
Bright and brilliant
Extraordinarily bright – ideal for hunting wild boar from a stand at twilight or at
night – thanks to Leica high performance optics with HDC™ multi-coating and a
front lens diameter of 56 mm. Outstanding image rendition, rich in contrast, with
neutral color rendition, razor-sharp all the way to the edges, more than satisfying
the highest demands in hunting.
Robust and comfortable
Uncompromised, precise function – even under the harshest conditions from
-15 to +50 °C (+5 to +122 °F). Secure and fatigue-free observation and range-
finding in every situation and over long periods of time, thanks to a well-balanced
weight distribution and to the optimal positioning of the operating elements.
Technical Data
Binocular LEICA GEOVID 8 x 56 BRF, black
Order No. 40 031
Delivery scope Neoprene carrying strap, eyepiece cover,
protective front lens cover, battery, Cordura case
Magnification 8 x
Front lens diameter 56 mm
Exit pupil 7 mm
Twilight factor 21.17
Field of view at 1,000 m 118 m
Eye-relief 18,5 mm
Objective angle of view 7.1°
Close focusing distance approx. 5.5 m
Diopter compensation ± 3.5 diopters
Distance measurement
Range 10 m to approx. 1,200 m
Accuracy ± 1 m up to 350 m ; ± 2 m up to 700 m ; ± 0.5 % beyond 700 m
Read-outs LED display with four digits, easily legible in any light
Eyepieces for
eyeglass wearers yes
Sliding eyecups yes, removable, with two click stops
Adjust. interpupillary dist. 58–74 mm
Focusing Internal focusing via central focusing device
No. of lens elements
(each side) 7, all with HDC™ coating
Prism system Roof prism with phase correction coating P40
Watertightness Watertight to a depth of 5 m
Housing Die-cast aluminium, nitrogen-filled
Dimensions (W x H x D) approx. 135 x 182 x 68 mm
Weight approx. 1,100 g
Meter/Yard selector no
Laser Eye-safe invisible laser according to EN and FDA class1
Laser beam divergence 2.4 x 0.5 mrad
Measuring time max. approx. 1.0 s
Measuring mode Scanning mode
Power supply 1 x CR2
Battery lifetime approx. 1,000 measurements at 20°C
Order No. Accessories
Neopren
carrying strap included
Floating
carrying strap 42 163
Tripod adapter 42 220
Trademark of the Leica Camera Group / "Leica" and product names = ® Registered trademarks / © 2005 Leica Camera AG / All rights to change construction,
design and range reserved / Concept and Design : Heine/Lenz/Zizka, Frankfurt am Main / Image indication : Product photography : Alexander Göhr
Natur photography : Franz Bagyi / Brochure order number : German 91217, English 91218, French 91219
Leica Camera AG / Oskar-Barnack-Straße 11 / D-35606 Solms
www.leica-camera.com / info@leica-camera.com
Telephone + 49(0)6442-208-0 / Fax + 49(0)6442-208-333
LEICA GEOVID 8 x 56 BRF
New perspectives for hunting in low-light
The first 8 x 56 with an integrated laser rangefinder :
innovative, bright, compact
