Specifications

Network Protocol:
PoE Standard:
PoE Voltage:
Power Pin:
AC Input Voltage:
Output:
Total Power:
Dimension (L x W x H):
Bandwidth:
MAC Address:
Pocket Buffer Memory:
Forwarding Mode:
Working Temperature:
Storage Temperature:
Working humidity:
Storage humidity:
Working hight:
Storage hight:
DIP explanation
VLAN Port Isolation
Default Standard Switch
Extend Link Extension
IEEE802.3/IEEE802.3u/IEEE802.3z
IEEE802.3x/IEEE802.3ab/IEEE802.3af/at
IEEE802.3at (30 W) and IEEE802.3af (15.4 w)
DC 48-55 V
Power over spare pairs 1/2 (+), 3/6 (-)
AC 100 240 V
52 V 2.3 A
120 W
320 mm x 210 mm x 46 mm
9.2 Gbps (non-blocking)
2K MAC address table
6.8 Mpps
Store-and-forward
-20 50˚C
-40 80˚C
Max relative humidity 90 %, non-condensing
Max relative humidity 95 %, non-condensing
Max 10 000 feet (3 000 meters)
Max 10 000 feet (3 000 meters)
Downlink designated ports are isolated from each
other, only transmit data with the uplink port.
All ports communicate freely.
The specified port speed drops to 100 Mbps/s, max
PoE transmission is 250 meters.
