Sun Microsystems Ultra Enterprise Caster Base Installation Manual page 5

Figures
Figure 1 Caster Base with Enterprise 4000 System and
SPARCstorage Array (Rear View) . . . . . . . . . . . . . . . . . . . . . . .
Figure 2 Caster Base with Enterprise 4000 System,
SPARCstorage Array, and SPARCstorage Library (Rear View)
Figure 3 Installing First Locking Module (Rear View) . . . . . . . . . . . . . .
Figure 4 Removing Chassis Cover Plugs. . . . . . . . . . . . . . . . . . . . . . . . . .
Figure 5 Installing the Left Shroud. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Figure 6 Installing First Chassis and Second Locking Module . . . . . . .
Figure 7 Completed Caster Base (Rear View). . . . . . . . . . . . . . . . . . . . . .
Figure 8 Completed Caster Base (Front View) . . . . . . . . . . . . . . . . . . . . .
3
4
6
7
8
10
11
12
v
