50340 — 11,000 RPM
WARNING
!
01185 Blade (4) 4/pkg.
50767 Pin
55025 Rotor
01743 Bearing Plate
55046 Guard Assembly
(Incl. 95876 Screw)
55029 Cover
Type 27 Depressed Center Wheel
(Not Included)
07139 Flange
55035 Trigger
50936 Pin
KEY
Oil
O
Loctite/Hernon:
L
L
= Loctite #271,
2
Torque: N•m x 8.85 = In. - lbs.
T
= 17 N•m, T
= 23 N•m,
T
2
3
T
= 28 N•m
4
Always operate, inspect and maintain this tool in accordance with the Safety Code for portable air tools
(ANSI B186.1 and B7.1) and any other applicable safety codes and regulations. Please refer to
Dynabrade's Warning/Safety Operating Instructions for more complete safety information.
55032 Governor Cage
O
Shims (as required)
96255 – 0.38" thick
96256 – 0.127" thick
96257 – 0.076" thick
55054 Governor Valve
02649 Bearing
95876 Screw
55034 Adapter
T
55031 Felt Ring
2
55052 Valve Stem
96069 Spring
55043 Trigger Post
See inside for Important Operating, Maintenance and Safety Instructions.
4-1/2" – 5" Pistol Grip
Depressed Center
Serial # 7B5604 and Higher. Machine and Motor Parts.
50938 Governor Pin (2)
50399 Governor Weight
55050 Housing
52182 Spring
T
2
01121 Shim (3/pkg.)
50767 Pin
01007 Bearing
55026 Bearing Plate
07138 Front Flange
55039 Bushing
02027 O-Ring (2)
50939 O-Ring
Parts Page Reorder No. PD97•48
Effective July, 1997
Wheel Grinder
95042 Washer
50470 Pin
95611 Spacer (6/pkg.)
50471 Spring Holder
96025 Pin
55024 Grip
01028 Cylinder
01010 Spacer
55051 Valve Stop
96147 O-Ring
55051 Valve Stop
55041 Valve
Supercedes PD96•79
53163 Handle
L
2
T
3
01494
Inlet
Bushing
57075
Cone
Muffler
57066
Muffler
Body
56028
Muffler Cap
