Assembly Instructions & User's Manual
for
Member's Mark Homewood 7pc Counter
Height Fire Pit Set
Item Number: 980297053
Model Number: FRM16024ZST
Customer Assistance
: 1-888-690-9800
(spare/replacement parts)
or Email: cs@sunvillahome.com
THIS ASSEMBLY MANUAL CONTAINS INPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
1 |
P a g e
Advertisement
Table of Contents
Related Manuals for Member's Mark FRM16024ZST
Summary of Contents for Member's Mark FRM16024ZST
- Page 1 Assembly Instructions & User’s Manual Member’s Mark Homewood 7pc Counter Height Fire Pit Set Item Number: 980297053 Model Number: FRM16024ZST Customer Assistance : 1-888-690-9800 (spare/replacement parts) or Email: cs@sunvillahome.com THIS ASSEMBLY MANUAL CONTAINS INPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
-
Page 2: Table Of Contents
Table of Contents Quality Statement ............................. 3 Important Safety Information ........................ 3 Before Assembly ............................3 Care & Use ..............................3 Package Contents ............................ 4 Product Information ..........................5 Components .............................. 5 Hardware ..............................5 Tools ................................6 Step 1 – Step 17 ............................6 Warning &... -
Page 3: Quality Statement
Quality Statement Important Safety Information • Please read all instructions carefully before assembling this product. • Where applicable, and for your safety, assembly by an adult is strongly recommended. • Use only vendor-supplied hardware to assemble this item. Using unauthorized hardware could jeopardize the structural integrity of the item. -
Page 4: Package Contents
Package Contents Component Description Quantity Component Description Quantity Table Top Chair Frame Table Base Chair Base Glass Beads Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e... -
Page 5: Product Information
Product Information Fire Pit Dimensions: 59.75”x38.75” (152cm x 99cm) Chair Dimensions: 27.50”x24.00”x45.25” (70cm x 61cm x 115cm) Chair Weight Capacity: Supports up to 250 lbs. (113.4kg.) Components Table Top Table Base Qty 1 Qty 1 Qty 1 Glass Beads Chair Frame Chair Base Qty 1 Qty 6... -
Page 6: Tools
Tools Wrench (Included) Step 1 – Step 17 Step 1 Step 2 Step 3 Step 4 KEEP GLASS BEADS away from Pilot Housing Screen Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e... - Page 7 Step 5 Step 6 DO NOT place Lid onto fire pit while hot If necessary, you can adjust the feet to level the table. Step 7 Step 8 Step 9 Battery may contain mercury. Do not put battery into the fire or trash. Please treat battery as hazardous waste and recycle properly Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e...
- Page 8 Step 10 Open the LPG tank valve and turn on the control knob. Push and hold the ignitor to create spark with electrode. Turn the control knob to adjust flame to desired height. Step 11 Turn off control knob and close LPG tank valve when not in use. Step 12 Once the unit cools down, place Lid onto burner.
- Page 9 Step13 Step14 Step15 Step16 If necessary, you can adjust the feet to level the chair. Step17 When furniture is not in use, put covers on them to prevent dust. Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e...
-
Page 10: Warning & Danger
Warning & Danger Installer: Leave this manual with appliance. Consumer: Retain this manual for future reference. This appliance is a Decorative Gas Appliance for OUTDOOR USE ONLY and MUST NOT be used for cooking. WARNING DANGER HOT! DO NOT TOUCH SEVERE BURNS MAY RESULT. - Page 11 A. Design and Installation Considerations WARNING Place the Fire Pit on a flat and stable surface in an Do NOT use this appliance if any part of it has outdoor location adjacent to the gas supply line or been under water. LP gas supply cylinder.
- Page 12 WARNINGS Installation and repair should be done by a qualified service person. The appliance should be inspected before use and at least annually by a qualified service person. More frequent cleaning may be required as necessary. It is imperative that the control compartment, burners and circulating air passageways of the appliance are kept clean. *Do not use this fire pit for cooking.
-
Page 13: Gas Hookup And Information
Gas Hookup and Information A. Fuel Note: A listed (and Common wealth of Massachusetts approved) 3/8 in. T-handle manual shut-off valve and Before making gas connections, ensure the appliance flexible gas connector are connected to the 3/8 in. being installed is compatible with the available gas type. Control valve inlet. - Page 14 FOR LIQUID PROPANE GAS UNITS *Do not attempt to disconnect the gas regulator or any gas fitting while your fire pit is in operation. *A dented or rusty liquid propane cylinder may be hazardous and should be checked by your gas supplier prior to use.
- Page 15 Note: Checking for leaks ● Illustrations reflect typical installations and are FOR DESIGN PURPOSES ONLY. 1. Make 2-3oz of leak detection solution by mixing one part liquid ● Illustrations / diagrams are not drawn to scale. dishwashing soap with three parts water. Actual installation may vary due to Make sure control knobs are in the “...
-
Page 16: Troubleshooting
Troubleshooting Problem Possible Cause Prevention / Solution No LP in tank. Check the LP (propane) tank. You may be out of gas. Or check Natural Gas valve at main. Fire won’t light Plugged burner orifice. Check the burner orifice for stoppage. Remove stoppage. -
Page 17: Storage Instructions
Storage Instructions 1. Carefully place all components into shipping box and/or provided container tape it shut. 2. When not in use, please store your item in a cool, dry place away from sunlight. 3. Exposing your item to excessive heat or humidity may damage your item. 4. -
Page 18: Warranty Information
Warranty Information This product component has a 3 years guarantee against defects in material and/or workmanship. If you have any questions regarding the warranty or spare / replacement parts, please call our toll-free number 1-888-690-9800 or email us at cs@sunvillahome.com NOTE: Please consider recycling all applicable packaging material.
