Assembly Instructions & User's Manual
for
Member's Mark Athena 4 Piece Deep Seating Set
980296848
Item Number:
FW-ANS4DS
Model Number:
Customer Assistance
: 1-800-443-1410
(spare/replacement parts)
customerservice@foremostgroups.com
or Email:
DISCLAIMER: Supplier is fully responsible for the entire content of the assembly manual, including
all Sam's Club suggested edits or revisions.
THIS ASSEMBLY MANUAL CONTAINS INPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
Advertisement
Table of Contents
Related Manuals for Member's Mark Athena FW-ANS4DS
Summary of Contents for Member's Mark Athena FW-ANS4DS
- Page 1 Assembly Instructions & User’s Manual Member’s Mark Athena 4 Piece Deep Seating Set 980296848 Item Number: FW-ANS4DS Model Number: Customer Assistance : 1-800-443-1410 (spare/replacement parts) customerservice@foremostgroups.com or Email: DISCLAIMER: Supplier is fully responsible for the entire content of the assembly manual, including all Sam’s Club suggested edits or revisions.
-
Page 2: Table Of Contents
Table of Contents Quality Statement ..........................3 Important Safety Information ......................3 Before Assembly ..........................3 Care & Use............................3 Package Contents ..........................4 Product Information ...........................5 Components ............................5 Hardware...............................6 Tools ..............................6 Step 1 – Step 2 .............................7 Step 3 – Step 4 .............................8 Step 5 – Step 6 .............................9 Step 7 –... -
Page 3: Quality Statement
Quality Statement portant Safety Information • Please read all instructions carefully before assembling this furniture. • For your safety, assembly by two or more adults is strongly recommended. • Use only vendor-supplied hardware to assemble this item. Using unauthorized hardware could jeopardize the structural integrity of the item. •... -
Page 4: Package Contents
Package Contents I、J、K Component Description Quantity Component Description Quantity Sofa Frame Table leg Club Chair Frame Shelf Adjustable Foot Furniture Cover-Sofa Seat Cushion Furniture Cover-Club Chair Back Cushion Furniture Cover-Coffee Table Table Top Need Assistance? Visit us at: samsclub.com/membersmarkhelp... -
Page 5: Product Information
Product Information Dimension: Stationary Lounge Chair: 37.80 “x 37.33” x 33.5” Sofa: 88.39” x 37.33 “x 33.5” Coffee Table w. Wicker Shelf: 43.03” x 29.02” x 22.05” Weight Capacity: Stationary Lounge Chair: 250lbs Sofa: 750lbs Components Component A Component B Component C Part No. -
Page 6: Hardware
Component J Component K Part No. PF-ANS-SC-E-20 Part No. PF-ANS-CT-D-20 Qty 1 Qty 1 Hardware Bolt (M6 x 35mm)AA Bolt (M6 x 20mm)BB Part No. PF-ANS-CT-HP-20 Part No. PF-ANS-CT-HP-20 Qty 4 Qty 4 Tools M6 Allen Wrench EE Part No. PF-ANS-CT-HP-20 Qty 1 Need Assistance? Visit us at: samsclub.com/membersmarkhelp... -
Page 7: Step 1 - Step 2
STEP 1 Place the Sofa Seat (A) on its side on a soft, smooth surface. Attach the Adjustable Feet (C) to the Sofa Seat (A) by turning the Adjustable Feet (C) clockwise and tightening. STEP 2 Place the Seat Cushions (D ) and Back cushions (E) on the sofa and check the stability. If the sofa wobbles, loosen the foot glider counter-clockwise until the sofa stands com- pletely stable. -
Page 8: Step 3 - Step 4
S T E P 3 Place the Chair Seat (B) at its side on a soft, smooth surface. Attach the Adjustable Feet (C) to the Chair Seat (B) by turning the Adjustable Feet (C) clockwise and tightening. S T E P 4 Turn the chair to the upright position and place the Seat Cushion (D) and Back Cushion (E) on the chair and check the stability. -
Page 9: Step 5 - Step 6
STEP 5 Place the Table Top (F) upside down on a soft, smooth surface. Loosely attach the Table Legs (G) to the Table Top (F) using Bolt (AA). Make sure the holes on the Table Legs (G) are facing inward. STEP 6 Loosely attach the Shelf ( H) to the Table Legs (G) using Bolts (BB). -
Page 10: Step 7 - Step 8
STEP 7 Turn the table to the upright position and check the stability. If the table wobbles, loosen the foot glider counter-clockwise until the table stands completely stable. The coffee ta- ble is ready for your enjoyment. STEP 8 Included is a complimentary Furniture Cover (I,J,K ). Use the Furniture Cover (I,J,K) to cover the furniture when not in use for long periods of time to prolong the life of your outdoor furniture Need Assistance? Visit us at: samsclub.com/membersmarkhelp... - Page 11 STEP 9 Elastic hem Buckle Strap with cord lock Buckle Strap Elastic hem Buckle Strap Elastic hem with cord lock with cord lock Use the buckle straps and the elastic hem to secure the furniture cover in place. Need Assistance? Visit us at: samsclub.com/membersmarkhelp...
-
Page 12: Warranty Information
Warranty Information Limited Manufacture’s 5 Years Warranty General Residential Warranty We warranty all our residential use furniture 5 years. The warranty is valid from the date you purchase and applies only to the original purchaser. If your frame fails structurally during normal usage (other than damage as a result of dropping or breaking a cast part other than a weld is not covered under this warranty) or if the finish peels, cracks or blis- ters within 1 year, we will repair , refinish or replace the frame at manufacturer’s discre-... - Page 13 Warranty Information Table Tops (if applicable ) All stone tops are warranted for a period for one (1) from original date of purchase, against defects in material and or workmanship. Breakage, discoloration, staining, and or any other weather-related issues are not covered. Firepits Bumer, cast aluminum &...
- Page 14 Distributed by Sam’s West Inc. 2101 SE Simple Savings Dr. Bentonville, Arkansas 72716-0745 Made in Indonesia Need Assistance? Visit us at: samsclub.com/membersmarkhelp...
