Assembly Instructions & User's Manual
for
Member's Mark Kimberly 7pc Dining Set
Item Number: TBD
Model Number: FRA10483SST
Customer Assistance
: 1-888-690-9800
(spare/replacement parts)
or Email: cs@sunvillahome.com
THIS ASSEMBLY MANUAL CONTAINS INPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
1 |
P a g e
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Member's Mark Kimberly TBD
Summary of Contents for Member's Mark Kimberly TBD
- Page 1 Assembly Instructions & User’s Manual Member’s Mark Kimberly 7pc Dining Set Item Number: TBD Model Number: FRA10483SST Customer Assistance : 1-888-690-9800 (spare/replacement parts) or Email: cs@sunvillahome.com THIS ASSEMBLY MANUAL CONTAINS INPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. P a g e...
-
Page 2: Table Of Contents
Table of Contents Quality Statement ............................. 3 Important Safety Information ........................ 3 Before Assembly ............................3 Care & Use ..............................3 Package Contents ............................ 4 Product Information ..........................5 Components .............................. 5 Hardware ..............................6 Tools ................................6 Step 1 – Step 12 ............................6 Troubleshooting ............................ -
Page 3: Quality Statement
Quality Statement Important Safety Information • Please read all instructions carefully before assembling this product. • Where applicable, and for your safety, assembly by an adult is strongly recommended. • Use only vendor-supplied hardware to assemble this item. Using unauthorized hardware could jeopardize the structural integrity of the item. -
Page 4: Package Contents
Package Contents Component Description Quantity Component Description Quantity Table Top Inner Cap 3 Table Legs Chair Frame Leg connector Chair Base Cast Cap Chair Seat Cushion Inner Cap 1 Furniture Cover Inner Cap 2 Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e... -
Page 5: Product Information
Product Information Dimensions: Swivel chair: 25.7''Dx23.6''Wx37''H (65.5cm x 60cm x 94cm) Table: 60x29.3''H (φ152.5cm x 74.5cm) Weight Capacity: Chair: Supports up to 250 lbs. (113.4kg.) Components Table Top Table Legs Leg connector Qty 1 Qty 4 Qty 1 Cast Cap Inner Cap 1 Inner Cap 2 Qty 1... -
Page 6: Hardware
Hardware M8x45 Bolt Washer Plate Spring Washer/Φ8xΦ13x2.0 Qty:24 (4 per chair) Qty:24 (4 per chair) Qty:24 (4 per chair) M6x12 Bolt/Φ12x1.6 Hole Metal Plate Qty:24 (4 per chair) Qty:16 Qty:4 Tools Wrench (Included) Hex Wrench (Included) Step 1 – Step 12 Step 1 Step 2 Need Assistance? Visit us at: samsclub.com/membersmarkhelp... - Page 7 Step 3 Step 4 Step 5 Step 6 Step 7 Step 8 Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e...
- Page 8 Step 9 Step 10 Step 11 Step 12 When furniture is not in use, put covers on them to prevent dust. Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e...
-
Page 9: Troubleshooting
Troubleshooting Problem Possible Cause Prevention / Solution Chair unstable Hardware may loosen overtime. Periodically check that all connections are tight. Storage Instructions 1. Carefully place all components into shipping box and/or provided container tape it shut. 2. When not in use, please store your item in a cool, dry place away from sunlight. 3. -
Page 10: Warranty Information
Warranty Information This product component has a 3 years guarantee against defects in material and/or workmanship. If you have any questions regarding the warranty or spare / replacement parts, please call our toll-free number 1-888-690-9800 or email us at cs@sunvillahome.com NOTE: Please consider recycling all applicable packaging material.
