Assembly Instructions & User's Manual
for
Member's Mark Cahaba 4pc Deep Seating
Set
Model Number: FZA10174ST
Customer Assistance
: 1-888-690-9800
(spare/replacement parts)
or Email: cs@sunvillahome.com
THIS ASSEMBLY MANUAL CONTAINS INPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
1 |
P a g e

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FZA10174ST and is the answer not in the manual?

Questions and answers

Summary of Contents for Member's Mark FZA10174ST

  • Page 1 Assembly Instructions & User’s Manual Member’s Mark Cahaba 4pc Deep Seating Model Number: FZA10174ST Customer Assistance : 1-888-690-9800 (spare/replacement parts) or Email: cs@sunvillahome.com THIS ASSEMBLY MANUAL CONTAINS INPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. P a g e...
  • Page 2: Table Of Contents

    Table of Contents Quality Statement ............................. 3 Important Safety Information ........................ 3 Before Assembly ............................3 Care & Use ..............................3 Package Contents ............................ 4 Product Information ..........................5 Components .............................. 5 Hardware ..............................6 Tools ................................6 Step 1 – Step 11 ............................6 Troubleshooting ............................
  • Page 3: Quality Statement

    Quality Statement Important Safety Information • Please read all instructions carefully before assembling this product. • Where applicable, and for your safety, assembly by an adult is strongly recommended. • Use only vendor-supplied hardware to assemble this item. Using unauthorized hardware could jeopardize the structural integrity of the item.
  • Page 4: Package Contents

    Package Contents Component Description Quantity Component Description Quantity Table Top Chair & Sofa Back Cushion Table Leg Sofa Frame Connector Furniture Cover For Table Chair Frame Furniture Cover For Chair Chair & Sofa Furniture Cover For Seat Cushion Sofa Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e...
  • Page 5: Product Information

    Product Information Dimensions: Table: 28.74”x48.03”x18.11” (73cm x122cm x 46cm) Chair: 31.88”x33.46”x34.44” (81cm x 85cm x 87.5cm) Sofa: 79.92”x33.46”x34.44” (203cm x 85cm x 87.5cm) Weight Capacity: Chair: Supports up to 250 lbs. (113.4kg.) Sofa: 250lbs (113.4kg.) per each seat Components Table Top Table Leg Connector Qty 1...
  • Page 6: Hardware

    Hardware M6x20/φ12x1.6 Bolt Qty: 8 Tools Hex Wrench (Included) Step 1 – Step 11 Step 1 Step 2 Step 3 Step 4 If necessary, you can adjust the feet to level the table. Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e...
  • Page 7 Step 5 Lift up the chair back to the upright position. To secure chair frame, snap bolt onto latch to lock in place. Step 6 Step 7 Place cushion shown as below before use. If necessary, you can adjust the feet to level the chair. Step 8 Lift up the sofa back to the upright position.
  • Page 8 Step 9 Step 10 Place cushion shown as below before use. If necessary, you can adjust the feet to level the sofa. Step 11 When furniture is not in use, put covers on them to prevent dust. Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e...
  • Page 9: Troubleshooting

    Troubleshooting Problem Possible Cause Prevention / Solution Table is unstable Hardware may loosen overtime. Periodically check that all connections are tight. Storage Instructions 1. Carefully place all components into shipping box and/or provided container tape it shut. 2. When not in use, please store your item in a cool, dry place away from sunlight. 3.
  • Page 10: Warranty Information

    Warranty Information This product component has a 3 years guarantee against defects in material and/or workmanship. If you have any questions regarding the warranty or spare / replacement parts, please call our toll-free number 1-888-690-9800 or email us at cs@sunvillahome.com NOTE: Please consider recycling all applicable packaging material.
