Eaton Crouse-Hinds SD Series Safety Manual

Safety manual
MTL Surge protection
Instruments signal connections
Surge Protection Devices
SD range, SD07/16/32/55 all versions and SDRTD, SD150X, SD275X.
SLP07D, SLP16D, SLP32D. IOP range, all versions. TP range, TP24/7, TP-
32, TP-48.
FUNCTIONAL SAFETY MANAGEMENT
FSM
These products are able to be used within a Safety System conforming to the requirements of
FUNCTIONAL SAFETY
MANAGEMENT
IEC 61508:2010 or IEC 61511. The products are not Safety Elements but may be used to
protect instrument loops designed to achieve Safety Integrity Level of up to SIL3.
IEC 61508:2010
Eaton is a certified Functional Safety Management company meeting the requirements of IEC61508 Part1:clause 6
DRAFT - 12 November 2016
November 2016
SM Surge Rev 2
SIL SIL SIL
1 2 3
IEC 61508:2010 IEC 61508:2010 IEC 61508:2010
