- Page 1 COOPER POWER Surge Arresters SERIES Effective February 2016 MN235005EN Lorem ipsum dolor sit Amat Supersedes IS235-35-1 June 2014 UltraSIL polymer-housed VariSTAR surge arrester IEC 60099-4 for MV systems to 36 kV installation instructions...
- Page 2 ANY CONTRACT BETWEEN THE PARTIES. In no event will Eaton be responsible to the purchaser or user in contract, in tort (including negligence), strict liability or other-wise for any special, indirect, incidental or consequential damage or loss whatsoever, including but not limited to...
-
Page 3: Table Of Contents
Contents SAFETY INFORMATION Safety information ................iv PRODUCT INFORMATION Introduction . -
Page 4: Safety Information
FOR LIFE FOR LIFE Eaton meets or exceeds all applicable industry standards relating to product safety in its Cooper Power™ series prod- ucts. We actively promote safe practices in the use and maintenance of our products through our service literature, instructional training programs, and the continuous efforts of all Eaton employees involved in product design, manufac- ture, marketing, and service. -
Page 5: Product Information
IMPORTANT CAUTION This product as designed and packaged by Eaton has Always handle surge arrester—packed or unpacked— been classified by the US DOT as not regulated as an very carefully. Do not drop, jar, or handle an arrester explosive. roughly. Dropping, jarring, and/or rough handling... -
Page 6: Installation Procedure
Make the arrester ground connection as short and Before performing any test on an arrester, contact direct as possible to a solid, effective, permanent, your Eaton representative. Some test procedures low-resistance ground. If the arrester has a ground may damage the arrester externally and/or internally,... -
Page 7: Removing An Arrester From A Circuit
MOUNTING HOLE FOR MOUNTING HOLE 1/2" OR 12 MM Ø FOR 1/2" OR 12 MM Ø HARDWARE HARDWARE ULTRASIL POLYMER-HOUSED ARRESTER – WITH ULTRASIL POLYMER_HOUSED ARRESTER – OPTIONAL INSULATING MOUNTING WITH OPTIONAL INSULATING MOUNTING BRACKET (NO ISOLATOR) BRACKET, AND DISCONNECTOR ULTRASIL POLYMER-HOUSED ARRESTER - ®... - Page 8 Eaton.com Eaton’s Cooper Power Systems Business 2300 Badger Drive Waukesha, WI 53188 Eaton.com/cooperpowerseries © 2016 Eaton All Rights Reserved Eaton is a registered trademark. Printed in USA Publication No. MN235005EN All trademarks are property February 2016 of their respective owners.
