iEP
Thank you for choosing another quality product from Amperes Electronics.
iEP1202 is a desktop version of ethernet based Emergency Paging Mic with additional features as compared to rack mounted
iEP1200. It can be placed at FCC or Security / Guard house where direct access with highest priority to PA system is more
convenient and faster.
Zone groupings and messages are programmable via web browser with user friendly UI. iEP1202 is an essential tool for
emergency broadcast in IP Network PA setup.
1202
ZONE GROUP KEYS
1
2
3
4
5
6
7
8
MESSAGE KEYS
1
2
3
4
INSTRUCTION MANUAL
Ethernet Emergency Paging Microphone
POWER
SERVER
STREAMING
SIREN / MIC
SIREN
iEP1202
MIC
Ver 3 / 2022
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Amperes iEP1202
Summary of Contents for Amperes iEP1202
- Page 1 Thank you for choosing another quality product from Amperes Electronics. iEP1202 is a desktop version of ethernet based Emergency Paging Mic with additional features as compared to rack mounted iEP1200. It can be placed at FCC or Security / Guard house where direct access with highest priority to PA system is more convenient and faster.
- Page 2 2. LED INDICATORS POWER - Light up when iEP1202 is powered ON. SERVER - Light up when iEP1202 successfully establish a connection with Paging Server (iPX5101). STREAMING - Blink whenever iEP1202 is streaming audio to Paging and Music Client (iPX5155).
- Page 3 Bootloader mode : To enter this mode, hold the Reset button until Power, Server, Streaming, Siren / Mic and Message LEDs lit. Only enter this mode for firmware updates when normal updating mode does not work. All iEP1202 settings and message library files shall remain intact.
- Page 4 Device Setup Via Browser Some initial setups are required as below. iEP1202 is to be connected with iPX5101 to form a complete system. The default address is 192.168.0.100. The login page shall appear with User ID and Passwords as “admin”.
- Page 5 To switch a message to another, e.g. while playing message 1, press again the key to stop and then press message 2. Activation of Siren or manual paging will override the message playback, either from the unit itself or from another iEP1202.
- Page 6 1. Press & hold the reset button until “SIREN / MIC” LED is turned ON. This will set the IP address to default add. 192.168.0.100. 2. Press & hold the reset button untill “STREAMING” LED is turned ON. This will make iEP1202 entering bootloader mode. 3. Open a browser and enter the IP address 192.168.0.100. A web page as shown below shall appear.
- Page 7 Dimension (WxHxD) 248 x 65 x 190 (excl. mic) Weight 900 g Note: The above specifications are correct at time of printing but subjected to changes without prior notice due to product improvements. iEP1202 | ETHERNET EMERGENCY PAGING MICROPHONE PAGE 7...
- Page 8 Only Amperes Electronics Service Centres are allowed to make warranty repairs : a list of Amperes Electronics Service Centres may be asked for by the purchaser or send directly to Amperes Electronics Sdn Bhd at 70 Jalan Industri PBP 3, Tmn Perindustrian Pusat Bandar Puchong, 47100, Puchong, Selangor, Malaysia or its authorized dealers.
