iEP
Thank you
for choosing another quality product from Amperes Electronics.
iEP1202 is a desktop version of Emergency Paging Mic which has added features as compared to the rack mounted iEP1200. It
can be placed at FCC, or Security / Guard House where direct access to PA is more convenient and faster. Similar to iEP1200 or
EP1200, it has highest priority over other audio sources such as BGM or normal paging.
There are 8 zone groupings that can be programmed, with each button to consist of one or many zones, eg, Button 1 to consist of
all zones in Building A. This is useful when it is only required to target certain building or zones for the emergency broadcast. Also
available are 4 preset messages that can be uploaded to the unit during setup. All the settings shall be done via web browser with
improved and simplified to be more user friendly.
1202
ZONE GROUP KEYS
1
2
3
4
5
6
7
8
MESSAGE KEYS
1
2
3
4
INSTRUCTION MANUAL
Ethernet Emergency Paging Microphone
MIC
POWER
SERVER
STREAMING
SIREN / MIC
SIREN
iEP1202
NEW
Ver 2/2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iEP1202 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Amperes iEP1202

  • Page 1 Amperes Electronics. iEP1202 is a desktop version of Emergency Paging Mic which has added features as compared to the rack mounted iEP1200. It can be placed at FCC, or Security / Guard House where direct access to PA is more convenient and faster. Similar to iEP1200 or EP1200, it has highest priority over other audio sources such as BGM or normal paging.
  • Page 2: Parts Identification

    2. LED INDICATORS POWER - Light up when iEP1202 is powered ON. SERVER - Light up when iEP1202 successfully establish a connection with Paging Server (iPX5101). STREAMING - Blink whenever iEP1202 is streaming audio to Paging and Music Client (iPX5155).
  • Page 3 Bootloader mode: To enter this mode, hold the reset button until POWER, SERVER, and STREAMING LEDs lit. Enter this mode to do firmware updating if normal mode updating does not work. All iEP1202 settings and Message Library files remain intact in this mode.
  • Page 4: General Connection

    2000 S E R IE S Equipment rack at Control Room or FCC (Main System) The above diagram shows general configuration of a decentralised rack connected to various IP based items through a network. PAGE 4 iEP1202 | ETHERNET EMERGENCY PAGING MICROPHONE...
  • Page 5: Connecting The Unit

    It can be placed in FCC or at Guard House, providing easier access to the system for emergency paging purpose. It shall have the same priority level with iEP1200. Additional advantage of iEP1202 is the Zone Grouping keys which can consists of up to 248 zones per button, and also dedicated message for broadcast which can be stored directly in the unit.
  • Page 6 Device Setup Via Browser iEP1202 shall require some simple setups, kindly follow the step by step instructions as listed below. The unit shall be connected to LAN network together with iPX5101 IP Server / PMX to form a complete system. The default IP address is 192.168.0.100. Login page shall appear and the default User ID and Password are both “admin”.
  • Page 7 Message Volume: Adjust volume level of playing message. Authentication: We can change the login user name and password here. Update Firmware: Update system firmware, please refer to “ Firmware Update ” section. iEP1202 | ETHERNET EMERGENCY PAGING MICROPHONE PAGE 7...
  • Page 8 MESSAGE KEYS 1,2,5,8,10-15,1-255 1,2,5,8,10-15,1-255 One of the most crucial part of iEP1202 setup is in this page. i.e. to assign the serving zone (s) to the Zone Group keys and assign media to Message keys. Programmable Zone Group Keys To assign several zones to a key, select “CUSTOM” and enter the zone number e.g. 1,2,10 - 15. If we select “CUSTOM” but not enter any zones, no zone will be called during paging.
  • Page 9 PC or mobile phone. Click the “UPLOAD” button when a dialog box as shown on the right prompted up to send the media to iEP1202. A remaining storage bar indicates available empty space left to store more media.
  • Page 10: Firmware Update

    1. Press & hold the reset button until “SIREN / MIC” LED is turned ON. This will set the IP address to default address 192.168.0.100. 2. Press & hold the reset button untill “STREAMING” LED is turned ON. This will make iEP1202 enter bootloader mode. 3. Open a browser and enter the IP address 192.168.0.100. A web page as shown below shall appear.
  • Page 11: Technical Specifications

    Dimension (WxHxD) 248 x 65 x 190 (excl. mic) Weight 900 g Note: The above specifications are correct at time of printing but subjected to changes without prior notice due to product improvements. PAGE 11 iEP1202 | ETHERNET EMERGENCY PAGING MICROPHONE...
  • Page 12: Warranty Conditions

    Only Amperes Electronics Service Centres are allowed to make warranty repairs : a list of Amperes Electronics Service Centres may be asked for by the purchaser or send directly to Amperes Electronics Sdn Bhd at 70 Jalan Industri PBP 3, Tmn Perindustrian Pusat Bandar Puchong, 47100, Puchong, Selangor, Malaysia or its authorized dealers.
