- Page 1 VECTECH ET9181 Desktop Soldering Machine Instruction Manual...
- Page 2 Thanks for purchasing our product! Read this book carefully before operation, please store it in a safety and available place for future reference.
-
Page 3: Table Of Contents
Content Safety Labels ................. 5 Characteristic ................. 7 2.1 Feature ..................7 2.2 Technical Data ................8 2.3 Dimension ................. 9 Functional Description..............10 3.1 Introduction ................10 3.2 Operation Keys Introduction ........... 11 Connection and Pin Function ............13 4.1 Connection ................ - Page 4 5.2.11 Lift Height ................22 5.2.12 Temp. Unit ................22 5.2.13 Password ................22 5.2.14 Language ................23 5.3 Calibration Menu ..............24 Commissioning ................25 6.1 Preparation ................25 6.2 Installation ................25 6.3 Beginning Program ..............25 Troubleshooting and Maintenance ..........30 7.1 Troubleshooting ..............
-
Page 5: Safety Labels
1. Safety Labels Serious warning The product poses a risk of electric shock. Only authorized person can change settings. Push the red emergency switch for power off in an emergency situation. Forbid working while the power wire was damaged. ... - Page 6 Do not move the movements by hands to avoid damaging the machine. Do not touch the moving parts in your work, or you may damage the machine or accident. During the operation of the machine, please do not put your hand into the device, which may cause the user to get injured or cause substantial damage to the object involved.
-
Page 7: Characteristic
2. Characteristic The machine is automatic feeder device with adjustable soldering parameters, and it is easy to be used. 2.1 Feature Heat and cool rapidly Equipped with foot pedal. Adjustable program speed/time, tin feeding/interval etc. Suitable for use with a wide variety of fixtures. ... -
Page 8: Technical Data
2.2 Technical Data Type QUICK ET9181 Power consumption 280W Input voltage 220V AC Temperature range 100～550℃ Temperature stability ±3℃ Available Tin Dia. 0.5、0.6、0.8、1.0、1.2、1.4、1.6（mm） Driver mode Motor Feeder type Foot pedal / Manual Soldering iron type 9018MG Dimension（L*W*H） 285*420*265mm Weight About 13kg... -
Page 9: Dimension
2.3 Dimension Front view Left View Unit: mm... -
Page 10: Functional Description
3. Functional Description 3.1 Introduction Soldering iron Wire feeder device Operation keys Foot pedal Baseplate Z Axis module Fume hose connector Tin tube 2-pin socket 6-pin socket Power socket Tin roll... -
Page 11: Operation Keys Introduction
3.2 Operation Keys Introduction Keys functions list: Command key Description Press “CH” to select channel, there are ten channels. 1. In Main menu, press and hold “SET” key for 3s to enter into Setup menu, refer to 5.2 Setup Menu. 2. - Page 12 Command key Description 1. In Main menu, press “-” key to decrease temperature by one digit, press and hold it to continually decrease. The Min temperature is 100℃. 2. In Setup menu, press “-” key to move the cursor down. Heater switch.
-
Page 13: Connection And Pin Function
4. Connection and Pin Function 4.1 Connection 1. 2-pin Socket: connect to foot pedal, pins function refers to 4.2.1 2-pin Socket Introduction 2. Power Socket: connect to power supply. 3. 6-pin Socket: connect to soldering iron, pins function refers to 4.2.2 6-pin Socket Introduction. -
Page 14: 6-Pin Socket Introduction
4.2.2 6-pin Socket Introduction 6-pin socket is connected to soldering iron, pins function refers to following table. Socket Pin No. Description Sensor - Sensor + Heat + Heat - No connection... -
Page 15: Menu Introduction
5. Menu Introduction Main Menu Icon Description Shows the channel number. 〓 Shows the temperature is constant. Red symbol indicates heating. Blue symbol indicates cooling. Shows the machine is in unlock mode. Shows the machine is in lock mode. ℃ Shows the temperature unit. -
Page 16: Setup Menu
5.2 Setup Menu Temperature 5.2.1 Temperature is used to set temperature value during soldering process. 1) In Main menu, press “SET” key to enter into Setup menu. 2) Press “+” or “-” key to move the cursor to Temp. 3) Press “SET” key to activate value (Blue indicates value can be modified). 4) Press “+”or “-”... -
Page 17: Z Speed
Z Speed 5.2.2 Z Speed is used to set the speed at which the Z axis moves during soldering process. 1) In Setup menu, press “+” or “-” key to move the cursor to Z Speed. 2) Press “SET” key to activate value (Blue indicates value can be modified). 3) Press “+”or “-”... -
Page 18: Pre-Tin
Pre-tin 5.2.4 Pre-tin is used to set the tin feeding length before soldering starts. 1) In Setup menu, press “+” or “-” key to move the cursor to Pre-tin. 2) Press “SET” key to activate value (Blue indicates value can be modified). 3) Press “+”or “-”... -
Page 19: Z Height
Z Height 5.2.5 Z Height is the distance that the Z axis moves down from home position. 1) In Setup menu, press “+” or “-” key to move the cursor to Z Height. 2) Press “SET” key to activate value (Blue indicates value can be modified). 3) Press “+”or “-”... -
Page 20: Pre-Tin Back
Pre-tin Back 5.2.7 Pre-tin Back is pre-tin back length. 1) In Setup menu, press “+” or “-” key to move the cursor to Pre-tin Back. 2) Press “SET” key to activate value (Blue indicates value can be modified). 3) Press “+”or “-” key to adjust length, the length range is 0～10mm. 4) Press “SET”... -
Page 21: Solder Time
Solder Time 5.2.9 Solder Time is used to determine how long the tip waits after finishing Tin Feeding. 1) In Setup menu, press “+” or “-” key to move the cursor to Solder Time. 2) Press “SET” key to activate value (Blue indicates value can be modified). 3) Press “+”or “-”... -
Page 22: Lift Height
Lift Height 5.2.11 Lift Height is a distance that the Z axis lifts when soldering finishes. 1) In Setup menu, press “+” or “-” key to move the cursor to Lift Height. 2) Press “SET” key to activate value (Blue indicates value can be modified). 3) Press “+”or “-”... -
Page 23: Language
4) Press “SET” key to save. 5) Press “ECS” key to back to Main menu. Language 5.2.14 Language is used to select the menu language, there are two languages can be selected. 1) In Setup menu, press “+” or “-” key to move the cursor to Language. 2) Press “SET”... -
Page 24: Calibration Menu
5.3 Calibration Menu In Main menu, press “ORG” key for 10s to enter into calibration menu, refer to following picture. Press “+”or “-” key to adjust number, and press “OK” key to confirm. If there are a “Cal OK” prompt appears, it indicates that the calibration process has been finished. -
Page 25: Commissioning
6. Commissioning 6.1 Preparation Inspection and maintenance are performed by professional person! Electrical shock hazard! Daily check items before operation: Check if the working voltage is correct. Check if the grounding is right. Check if there are obstacles on the machine. ... - Page 26 Hand Crush! This label warns of moving parts that can cause serious injury to hands and fingers. 1. Connect soldering iron and foot pedal. 2. Connect 220V AC cable to power socket. 3. Power on the machine. 4. Setting parameters. 1) Press “SET”...
- Page 27 6. Parameters Setup Press “+” or “-” key to move the cursor to Pre-length, press “SET” key to enter, then press “+” or “-” key to adjust value, press “SET” key to save. Press “+” or “-” key to move the cursor to Heat time, press “SET” key to enter, then press “+”...
- Page 28 Press “+” or “-” key to move the cursor to Solder Time, press “SET” key to enter, then press “+” or “-” key to adjust value, press “SET” key to save. Press “+” or “-” key to move the cursor to Tin Speed, press “SET” key to enter, then press “+”...
- Page 29 7. Starting Program Press foot pedal to activate program when the parameters have been set. Note: If you have any problem during operation, please contact us for technical supporting!
-
Page 30: Troubleshooting And Maintenance
7. Troubleshooting and Maintenance 7.1 Troubleshooting Error Message Description Heating element is damaged, replace a new one. Sensor is damaged, replace a new one. 7.2 Maintenance Wire Feeder Device 7.2.1 Regularly check and clean the wire feeder tube with a small brush and alcohol solvent. - Page 31 3. Choose the right type of soldering tip. 4. The plating would be broken if the tip is bent. Do not use the soldering tip as a detecting tool. 5. Activated rosin will corrode the tip plating. Choose the solder wire with less activated rosin.
