- Page 1 VECTECH 963D Self-Feeder Soldering Station Operation Manual Thank you for purchasing a Self-Feeder Lead Free Soldering Station. Please read this manual before operating the unit. Store this manual in a safe, easily accessible place for future reference.
- Page 2 CAUTION ● Appliance shall only be used with rated voltage and frequency. (Refer to the nameplate back of the unit) ● Don’t use or stop the use if the appliance is damaged, especially the supply cord. ● Please avoid an abuse of the equipment, use the appliance only in the described manner. ●...
-
Page 3: Section 1 Summary
SECTION 1 Summary The unit is Automatic self-feeder lead free soldering system. Digital display, adjusting with button, furthermore, design with automatic sleep and digital calibration function, easy and prompt to use. Adopt step motor, feeding precise and the precision is controlled optionally. Feeding speed and time, returning are all adjustable and steady, reach to perfect soldering effect and high efficiency. - Page 4 * Both of Pedal switch and Manual switch can be use. * It is used as Lead Feed Soldering Irion. * ESD safe by design to avoid damaging sensitive element because of static. SECTION 4 Panel Picture Display Window Temperature Bottom Digital Switch Power Switch SECTION 5 Combination...
- Page 5 SECTION 6 Product picture and parts name Main Unit Feeder Tube Assembly (0.46m Short Tube) Feeder Tube Assembly (0.8m Long Tube) Feeder Tube (0.46m)
- Page 6 Feeder Tube (0.8m) Guide Tube Assembly (Using for top Feeding ) Guide Tube Assembly (Using for bottom Feeding) Parts name: Main unit Item No. Part Name Description 1, 2 Handle Bracket Assembly Handle clamping element Handle Bracket Assembly Lead free soldering iron handle assembly Handspike Pressure adjusting screw Feeder tube assembly...
-
Page 7: Section 7 Installation
Feeder Tube Assembly: Item No. Part Name Remark Guide Tube Locking Screw Connector Plug Feeder Tube Head SECTION 7 Installation Before installation, please check the parts and make sure whether the power supply voltage accords with the nameplate. 1. Install Handle Bracket assembly to the unit Screw off the Nut ①... - Page 8 until the solder wire is sent out. Turn off power switch. 5.Install Soldering Iron Screw off Nut ② on the bracket assembly and remove Handle clamping element ③. Place soldering iron in the other Handle clamping element and install the previous one (Make the Handle in the middle of them), and then screw on Nut ②.
- Page 9 range is about 2.7mm/s to 27mm/s. 2. Feeding Length setting Feeding Length is designed with angle system, namely, with angle what the motor turned denotes Feeding Length. Feeding Length is designed with three digit. 001 to 999 denotes feeding length is 0.15mm to 150mm.
-
Page 10: Section 9 Set Temperature
with 360º/s. Example: When the digit is set as 1, the returning time is 0.1 second and the returning length is 2.8mm. The digit is set as 2, the returning time is 0.2 second and the returning length is 5.6mm. When the digit is set as 9, the returning time is 0.9 second and the returning length is 25mm. - Page 11 the displayed value as shown below. 1234567890 Press the “*” button. The right (the 1’s digit) will then begin flashing to indicate that the 1’s digit can be set. 4. Select the desired value for the 1’s digit. Using the “▲” or “▼” button will change the displayed value as shown above for the 10’s place selection..
-
Page 12: Section 10 Set Password
Temperature dropping: Don’t press “*” knob, and press “▼” knob directly. If so, the setting temperature will drop 1℃ and the display window will display the set temperature. When loose the “▼” knob, the display window will relay the set temperature about 2 seconds. If within 2 seconds , press the “▼”... -
Page 13: Section 11 Set Working Mode
Input New Password , press ”*” button, and shows 7. When display window is showing , It indicates the unit comes into inputting new password state. Pressing“▲”or“▼”button will change displayed value. See “set temperature normally”. Repeat the new password 8. When three digits press”*”... - Page 14 200℃-480℃ High frequency 90W Station soldering iron 200℃-420℃ High frequency 60W Station soldering iron 200℃-420℃ High frequency 90W Station soldering iron 200℃-420℃ High frequency 60，90W tweezers or using Station special very large type of soldering tip 50℃-600℃ High frequency 90W Station tweezers stripper 50℃-420℃...
-
Page 15: Section 13 Temperature Calibration
(If the set temperature is more than or equal to 200℃) or 50℃ (If the set temperature is less than 200℃) and remain the temperature until resuming the unit. To resume soldering , there are several ways as follows: 1. Turn the power switch OFF , then ON. 2. - Page 16 useless when the Feeding Mode is set as manual. Auto: Turn on Power Switch. The unit will work according to setting parameters when stepping on pedal switch or pressing Touch Switch once. All functions are useful SECTON 15 Tip care and use 1．...
- Page 17 1. Turn the nut ① anticlockwise and remove the tip enclosure ② and the tip ③. 2. Turn the nipple ④ anticlockwise and remove it from the iron. 3. Pull Heating Element ⑩ out of Handle ⑦. (Toward the tip of the iron). 4.
- Page 18 Sensor Spring Heating Element Sensor Element SECTION 17 Replaceable Part Damageable part can be replaced by customers themselves. 1. Replace Soldering tip Screw off the metal nut of Soldering tip anti-clockwise and remove tip enclosure and Soldering tip. Put a new Soldering tip on heating element, and tighten nut. Note: To avoid scald, replacing when it cools down.
- Page 19 47436-1.2 Feeder Tube Assembly（0.8m）ø1.2mm 47436-1.4 Feeder Tube Assembly（0.8m）ø1.4mm 47436-1.6 Feeder Tube Assembly（0.8m）ø1.6mm Guide Tube Assembly ø0.6mm 47022-0.6 Using on the top of Tip Guide Tube Assembly ø0.8mm 47022-0.8 Using on the top of Tip Guide Tube Assembly ø1.0mm 47022-1.0 Using on the top of Tip Guide Tube Assembly ø1.2mm 47022-1.2 Using on the top of Tip...
- Page 20 Tips ? 4 .2 ? 3.2 ? 2.4 ? 1.6 ? 1.2 ? 0.8 ? 4 .7...
